This guide provides in-depth instructions on how to remove and replace a hard drive in the Acer Aspire V5-131-2629
If the hard drive is experiencing clicking, program crashes, error messages while running software, or any strange behavior that hasn’t happened until recently, it may be due to replace it.
The process will give a step by step instruction from removing the cover and taking out the hard drive itself.
Unfortunately, the Acer website has taken down information regarding this device. However, a basic, rather informal summary of the details and specs can be found at the following link:
++Acer Aspire V5-131-2629 prices and specs++
A general disassembly tutorial of the device can be found:
++How to Disassemble the Acer Aspire V5 131++
Outside Resources-
The link to replacement hard drive can be found at:
Werkzeuge
Ersatzteile
-
-
Carefully turn your Acer Aspire V5-131-2629 upside down, so that the battery cell is visible and nearest to you.
-
-
-
Identify the small, oval slide switch on the left hand side of the laptop, directly above the battery.
-
-
-
Insert an opening tool into the hole on the right side of the oval switch. Use the opening tool to slide the switch to the right.
-
-
-
With the switch engaged to the right, firmly pull the battery out and towards yourself, parallel to your work surface.
-
To reassemble your device, follow these instructions in reverse order.
