BlackBerry Curve 8900 Speaker Replacement

Geschrieben von: Johnny Tran

Kommentare: 9

BlackBerry Curve 8900 Speaker Replacement

Schwierigkeitsgrad

Moderate

Schritte

Zeitaufwand

20 - 30 Minuten

Einleitung

This will guide you on how to dissassemble your blackberry curve to replace the broken speaker with a new speaker.

Werkzeuge

Ersatzteile

BlackBerry Curve Speaker Module

Schritt 1

Remove the back cover of the phone.
The battery will now be visible.

Pry off the back and separate it from the front of the phone case. You should see the battery once you pry the back off.

(rewriting the second sentence)

You will see the battery once the cover is removed.

Aubrey - 12/03/15

Schritt 2

Use your fingers to pinch the battery at the grey semi-circles on the edges of the battery and remove it from the device.

On both sides of the battery, there is a lighter grey half-circle. This is the best place to use your fingers to gently lift the battery free of the housing. Set aside the old battery, then replace it with the new battery. It should easily fit into place.

(deleted "it sits in") from second sentence

Aubrey - 12/03/15

Replace backing of phone, pressing gently to secure to back of phone case ( There seems to be a bit of repetition in this sentence so I rewrote it.)

Reattach the back cover by pressing gently until cover is secure.

Aubrey - 12/03/15

Schritt 3

Using a small iFixit opening tool, remove the lower rear cover.

Schritt 4

From the mid-frame of the device, use a screwdriver to remove the six screws.
Set the screws aside once they've been removed.

Should say something like ‘Beginning from the middle of the device begin removing screws with a screwdriver…’ or ‘Using a screw driver, begin removing screws from the middle of the device…’ instead

Deepika Sawyer - 28/04/21

Schritt 5

Gently remove the mid-frame from the phone, exposing the motherboard.
This is the motherboard.

Schritt 6

Gently pull back the plastic tabs that secure the motherboard to the case.
Slowly work your way around the case until the tabs are lifted and the motherboard is free.
Remove the motherboard.
The keypad and navigation ball may become loose and fall off the motherboard.

First bullet should be red

Deepika Sawyer - 28/04/21

Schritt 7

Carefully detach the antenna from the two clips on the side of the motherboard.
In the same manner, disconnect the antenna from the motherboard.

Schritt 8

Carefully disconnect the ribbon cable located on the bottom right of the motherboard.

Bullet should be red

Deepika Sawyer - 28/04/21

Schritt 9

Gently remove the screen, taking care not to damage it by applying too much pressure.

‘…by applying too much pressure…’

forgot much

Deepika Sawyer - 28/04/21

bullet should be red

Deepika Sawyer - 28/04/21

Schritt 10

Lift up the motherboard from the bottom edge to reveal the ribbon cables.
Carefully disconnect the two ribbon cables connecting the motherboard to the display.
Remove the motherboard.
