Blackberry Key 2 LE Keyboard Replacement

Use your phillips screwdriver to begin removing all the accesible screws.

Now begin to remove the coverings above and below the middle plate with your hand.

use your hand or a tool to remove the tabbing on the metal plate covering the battery.

Remove the metal plate covering the battery.

Use your wedging tool to begin removeing the adhesive under the battery.

Remove these two screws with your phillips screw driver.

Open the two metal tabs

Flip the phone back over with the screen facing you.

Begin to use the wedging tool to remove the space bar off of the keyboard.

remove the screws on each end of the space bars vacant lcoation.

Grab the wedging tool and begin wedging the old keyboard.

begind wedging the back of the keyboard until free.

Begin deperating the keyboard from the backing.

grab your replacement keyboard and connect it to the backing of the old keyboard.

place the keyboard back onto the front of the phone

once placed, hold the keyboard onto the phone while clicking the two metal plates back down to connect the keyboard.
