Dell Latitude 7390 SSD Replacement

Geschrieben von: Thomas Pryor

Kommentare: 0

Schwierigkeitsgrad

Moderate

Schritte

Zeitaufwand

20 - 30 Minuten

Einleitung

This guide will demonstrate the process on how to replace the Solid State Drive (SSD) card in the Dell Latitude 7390.

The SSD’s primary purpose is to store data on the laptop and can last generally up to 10 years. However, factors including temperature change, external or internal damage shocks, or even virus attacks just to name a few can require replacement sooner.

Before beginning this repair, be sure to power off the laptop and disconnect from the power adapter.

Werkzeuge

Ersatzteile

Dell F3YGT Battery

Schritt 1

Orient your Dell Latitude 7390 laptop so that it is facing towards you as if you're going to open it.

Schritt 2

Flip your laptop over so that the bottom is facing up.

Schritt 3

Using your Phillips #1 screwdriver, remove the eight 6 mm screws around the border of the bottom panel.

Schritt 4

Using an opening tool or picks, work your way around the periphery and pry the back case off.

Schritt 5

Finally, lift the back panel off to uncover the inside of your Dell Latitude 7390.

Schritt 6

Make sure the laptop is turned OFF and unplugged from the power adapter before taking the battery out.
Use the Phillips #1 screwdriver to remove the five 6 mm screws holding the battery in place along the edges of the battery.

Schritt 7

Be careful not to break the connector by pulling too hard on the black tab.
Pull the black tab on the top of the connector to unplug the battery from the motherboard.
