Garmin Nuvi 50LM Power Button Replacement

Geschrieben von: Maurice Thomas
  • Kommentare: 3
Garmin Nuvi 50LM Power Button Replacement

Schwierigkeitsgrad

Very easy

Schritte

3

Zeitaufwand

10 Minuten

Einleitung

There are times when the power button might fall off the device. If that happens, refer to this guide in order to replace it.

  1. FGyGoQ3rVI43Pyup
    FGyGoQ3rVI43Pyup
    qWGZP3EHSQiSnCSW

    • Use the T-4 screwdriver to unscrew the 9 mm screws on the back of the device.

  2. jE3h6DhD3QKvUNxy
    jE3h6DhD3QKvUNxy
    jRZXAvyWrOQeiBoN

    • Pry open the device from all four sides using the iFixit Plastic Opening Tool until you see the inside of the system.

  3. gQ2oiJ1wnr2Lcvhm
    gQ2oiJ1wnr2Lcvhm
    r1usXPrsdHIxZRYV

    • Look for a small button on the motherboard at the top of the device, and insert replacement power button on top of the small button on the motherboard until you hear a click.

Abschluss

To reassemble your device, follow these instructions in reverse order.
