This replacement guide is for the touchpad of the HP Envy x360 m6-w103dx. The touchpad is used for moving the cursor. All you need to complete this guide is a plastic opening tool, and a #0 Phillips screwdriver.
Make sure the computer is unplugged and powered off before touching any internal parts.
Removing the touchpad is not dangerous and doesn’t require any special technical skills.
-
-
Unscrew the twelve 6 mm screws from the bottom of the laptop using a Phillips #0 screwdriver.
-
-
-
Open the laptop carefully, with the keyboard face up.
-
Pry around the outside of the keyboard with the plastic opening tool until the keyboard can be lifted slightly.
-
-
-
Lift the keyboard until you can see the cables connected to the motherboard.
-
Gently lift the tab on each ZIF connector that connects each cable to the motherboard using a spudger. Once each tab is flipped up, the corresponding ribbon cable will come out easily.
-
Detach the keyboard.
-
-
-
Unplug the ribbon cable by flipping up the white tabs on the ZIF connectors and gently sliding the ribbon cables out of their sockets.
-
Unplug the battery connector by grasping the small white tabs on either side of the connector and pulling down towards the battery.
-
To reassemble your device, follow these instructions in reverse order.
