HP Pavilion 15-ab243cl Hard Drive Replacement

Geschrieben von: Alexander Bicigo

Kommentare: 2

HP Pavilion 15-ab243cl Hard Drive Replacement

Schwierigkeitsgrad

Moderate

Schritte

Zeitaufwand

15 - 45 Minuten

Einleitung

This guide will show you how to open your device and remove the hard drive. Whether you have a failed hard drive or simply want to upgrade to more capacity this guide will take you through the necessary steps involved in replacement.

Werkzeuge

Schritt 1

Slide the battery lock tab toward the center of the battery to the unlock position.

Before starting, open the CD drawer and leave it open. This makes Step 5 - sliding out the CD drive - far easier. If left closed, prying open the CD drive can damage it. Power down the laptop and begin.

Stuart - 29/05/20

Schritt 2

Slide the battery release switch to the right until the battery pops out.

Schritt 3

Grabbing the top edge of the battery, rotate it toward you and then lift upward to relieve the battery from its slot.

Schritt 4

With the battery removed, remove both black plastic covers with a plastic opening tool. Unscrew both 7.5 mm screws from the tabs, using a PH1 screw driver. Using a plastic opening tool, pry off both covers.

Schritt 5

Remove all 16 of the 3.5 mm screws with a PH1 screwdriver and pry/slide the CD drive out of laptop.

Schritt 6

With the CD drive removed, unscrew the two 2mm silver screws with a PH00.
These can strip easily, so take your time removing.

Schritt 7

Using a plastic opening tool, begin to pry edge of case away from the laptop. Work around the edges until all sides, except back, are open.

Schritt 8

On the back side of the laptop, where the battery is, there are 12 black plastic clips. Use a plastic opening tool and pry all of these clips, unlatching them from the case.
Once clips are free, open the laptop. Rotating the case off, around the hinges, works best to remove the case.

To unclip the back of the case, I found I only had to free the 8 smaller clips in the battery compartment. The 4 larger ones seemed to be guides for reassembly.

Neil Brown - 30/01/19
