HP Pavilion 15-au123cl Hard Drive Replacement

Geschrieben von: Mohammad Gardezi

Kommentare: 4

HP Pavilion 15-au123cl Hard Drive Replacement

Schwierigkeitsgrad

Moderate

Schritte

Zeitaufwand

15 - 20 Minuten

Einleitung

If you have noticed that your computer is no longer booting up and you have come to the conclusion that the hard drive is the problem, this guide will walk you through the sets to replace the hard drive. You will first remove the battery and then the hard drive. Using the tools suggested, you should have no problem removing the hard drive.

Werkzeuge

Ersatzteile

Schritt 1

Make sure the laptop is off and unplugged before starting.
Using the plastic opening tool, remove the top rubber feet on the back panel as it hides one of the screws we will be removing.

Schritt 2

Using a PH0 screwdriver, unscrew the ten 4.4mm Phillips head screws located on the back panel.

Correction. Top two screen pivot screws are bigger than the 8, 4mm.

Mitchell Culp II -

Schritt 3

Using the plastic opening tool, remove the back cover of the laptop.
It is recommended that you start with a corner and run the tool throughout the edges of the cover.
Be sure not to bend the cover by applying too much force.

What? I think you have have neglected to mention the DVD drawer. I believe it needs to be pulled out after removing the center screw and before removing the cover.

Dan Enslow - 25/01/19

Yes, best to remove the drawer as recommended. Also there are 3 screws holding the battery, not 2.

Lastly, pay careful attention to the orientation photo when removing the back.

I did not have the plastic tool but used a small Teflon type kitchen spatula and it did the trick. Do not use a metal screw driver or other such tool.

Edward Yandek - 01/09/19
