Einleitung
The battery of the HP Pavilion is made to last for only a period of time, after which the battery tends to run low sooner than usual. This means the battery capacity has lessened and may need a replacement. This guide will walk you through the process of accessing the RTC Battery of an HP Pavilion dv5000 in order to replace it.
Werkzeuge
-
-
Lay the computer face-down on a flat surface. Orient the computer to match the image.
-
Locate the battery release switch, as indicated in the image by the red rectangle. Slide the switch from right to left, and remove the battery.
-
-
-
Remove the two 5mm Phillips screws on the right side of the RAM cover.
-
Lift the right side of the RAM cover, and remove it.
-
-
-
Disconnect the antenna leads from the wifi card by lifting the gold ends of the wires off the prongs on the wifi card.
-
The white wire connects to the AUX terminal.
-
The black wire connects to the MAIN terminal.
-
To reassemble your device, follow these instructions in reverse order.
