Einleitung

If you need to replace hard drive in your HP Pavilion g7-1150us use this guide. The hard drive holds all the information stored on your laptop so if you have error saying your hard drive has been corrupted try replacing it. You will need an iFixit opening tool and Phillips #0 screwdriver. No steps are difficult but make sure to remove the battery first so you don’t hurt your laptop or yourself.

  1. NM4ApCRVJYTgZu1y
    NM4ApCRVJYTgZu1y
    Gan2IyByheLbOGtR
    • Slide the battery removal switch towards the center of the laptop until the battery pops out.

  2. KNP6GQkduG6LyarI
    • Remove the battery from the computer.

  3. PmKbYOPqIcXAQNFG
    • Unscrew the two 4mm Phillips #0 screws found in the surface panel.

  4. SRwNiOMIHv1ubHBy
    SRwNiOMIHv1ubHBy
    XUMSc3SZQrhuNmAr
    • Using the spudger, pry the surface panel off starting from the side where the battery was located.

    • Pry the remainder of the panel off by sliding the spudger underneath the panel and gently lifting.

    • Aim for the corners of the panel while using the spudger to methodically remove it without damaging it.

  5. FpNrSDZ2tCPKj6oN
    • Lift the pried surface panel off of the computer.

  6. iy1tCNaukRPYiWEV
    • Grab the hard drive gently on either side. The left side is where the hard drive is connected to the laptop.

    • The hard drive was missing from our device.

  7. tTjU3qjkLol1QE4X
    • Gently pull the hard drive to the right away from the connector. When fully disconnected you have safely removed the hard drive!

Abschluss

To reassemble your device, follow these instructions in reverse order.
