HP ProBook 4320t RAM Replacement Guide

Schwierigkeitsgrad

Easy

Schritte

8

Zeitaufwand

10 Minuten

Einleitung

If your computer is running slowly or not downloading as quickly as you would like, replace the RAM card to an upgraded version.

  1. eJPQWwWwfpLmmrPo
    eJPQWwWwfpLmmrPo
    2TYHTHnYZJipYWSQ

    • Flip the laptop upside down and remove battery by pressing inward on the two latches holding the battery in.

  2. QDwMx1ZRBpZkEkNr
    QDwMx1ZRBpZkEkNr
    HwTZpyrDus6ipZEI

    • Unscrew the four (2.5 mm Phillips) screws (Use Phillips #0 Screwdriver).

  3. vfDtHGboeVeDUPmR

    • Flip laptop over and open it.

  4. 2RPAPievNLWkMjln

    • Slightly push up while lifting up on the power button panel to release the panel.

  5. wQ1PKuNqRsyPH4em

    • Unscrew the four (2.5 mm Phillips) screws holding the keyboard in (Use Phillips #0 Screwdriver).

  6. QWfMpR2gLrbvQK4a
    QWfMpR2gLrbvQK4a
    kXbFftDixY46Wdxt

    • Carefully (holding both sides of the keyboard), push up and lift slightly.

    • Keyboard is still connected via a ribbon cable.

    • Move the keyboard slightly to the left to have access to the keyboard ribbon cable.

  7. 4JYKaoI3xmpGFTaJ

    • Use the black spudger to lift the black latch holding the keyboard ribbon cable.

  8. X3F2LjyWRBbU2HSc

    • Press the two prongs outward, and the RAM card will come out of PCI Express connector.

Abschluss

To reassemble your device, follow these instructions in reverse order.
