Kindle Touch Speaker Replacement

Geschrieben von: Adam Yerly

Schwierigkeitsgrad

Moderate

Schritte

Zeitaufwand

15 Minuten

Einleitung

Use this guide to properly replace your speakers.

Use the plastic opening tool to undo the ten plastic clips around the back panel of the Kindle.

Wear work gloves as the tool can easily slip and stab you in the hand.

There are four tabs on each side.The two nearest the top are open at the top, hence they slide out (back towards the power connector end.

This is important in the reassembly stage:

1. Align the back cover about 0.75 cm away from the top

2. Hold the top half of the cover flat against the unit, and flex the cover away from the case a little at the bottom

3. Slide the top and the first two clips parallel to the case

4. snap the remaining bottom clips in place

Using a Phillips #00 screwdriver, remove the six 4 mm screws to access the front plate.

Use the plastic opening tool to pry the bezel from the top and sides
The bottom of the bezel will be glued, so be careful when sliding the clips out.
The clips can be easily bent, so do not try to force them out. If you do bend some, they can be bent back.

Use your Phillips #00 srewdriver to remove the indicated screws.
There are three pairs of screws that are each different. The screws on the top corners are 4 mm #00 Phillips screws, the screws on the bottom corners are 2 mm #00 Phillips screws, and the black bottom center screws are 6 mm #00 Phillips screws.
