Einleitung
If your LG G7 ThinQ (model IMEI 358159091436289) is producing distorted, intermittent, or no sound from the external speakers, use this guide to replace the speaker system.
The speaker system produces all the sound/audio that exits the phone. A faulty speaker will produce distorted or no audio.
Before using this guide, inspect the speakers for debris that may be interfering with sound quality. Typically, a small buildup of dust can be removed using an ESD-safe brush or small dust blower.
Before beginning, make sure the phone is powered off and is disconnected from any source of power.
-
-
Insert a SIM card eject tool into the hole in the SIM card slot on the top right of the phone.
-
After the SIM card tray is ejected, remove the SIM card tray from the phone.
-
Remove the SIM card from the tray.
-
-
-
Place the phone so the back cover is facing upwards.
-
Insert the opening picks one by one onto each side with equal pressure.
-
Use the pick with the best leverage to pry the back cover away from the phone.
-
-
-
Remove the screws along the perimeter and central area of the phone using a Phillips #000 screwdriver.
-
To reassemble your device, follow these instructions in reverse order.
