Lenovo Yoga 920-13IKB Fingerprint Sensor Replacement

Geschrieben von: Alyssa McCulloch

Kommentare: 2

Lenovo Yoga 920-13IKB Fingerprint Sensor Replacement

Schwierigkeitsgrad

Moderate

Schritte

Zeitaufwand

10 - 15 Minuten

Einleitung

This guide shows how to replace the fingerprint sensor on the Lenovo Yoga 920-13IKB.

Werkzeuge

Schritt 1

Flip the device over to access the screws on the back cover.
Remove the ten 5mm Torx T5 screws on the back cover to loosen the back cover.

Schritt 2

Slide the iFixit Opening Tool under the back cover to lift it up.
Pull up on the cover with your hand to release the tab holding the center of the cover in place.

Die Mitte der unteren Abdeckung wird von zwei Plastiknoppen am Gerät gehalten. Wenn die Schrauben gelöst sind, mit beiden Händen unter die Abdeckung greifen und nach oben gerade wegziehen.

Captainquark -

Schritt 3

Remove the four 5mm Phillips #00 screws that hold the battery in place.

Schritt 4

Grab the grouping of wires with your fingers close to the connector and gently pull to disconnect the battery from the motherboard.
The wire grouping is located underneath the thin flap near the center of the battery.
Do not lift the battery out before disconnection from the motherboard to prevent shortages or damage.

This was the hardest step for me. My comments: The thin flap covering the wires is just a flap of the plastic covering around the battery. The connector fits tightly, needs to be really tugged out. You may need to bend the group of wires to get the new connector to seat in place. There will be a thin edge of the connector still sticking out when you have it seated. I needed to use a very thin bit from the ifixit kit to press the new connector into place. Great guide, worked perfectly!

Spr -
