Motorola V60i Keypad Replacement

Flip the phone over so the back cover is facing up.

Using either a finger or a spudger, press the button located near the top of the phone by the antenna.

Pry up the back plate from the phone.

Push the button near the bottom of the battery using either your finger or the spudger to release the battery.

Using a T6 Torx screwdriver, remove the four screws from the back of the phone.

Simultaneously press the highlighted buttons on both sides of phone.

Separate the back plate from the rest of phone.

Gently lift logic board from back plate.

Place logic board on front cover.

Unsnap orange wire that connects the logic board to keypad sensor to allow the logic board to move freely.

Once logic board is removed lift the green keypad sensor for the front plate.

To replace keypad buttons, lift off white tray containing buttons.
