Nokia 6310i Keypad Replacement

Geschrieben von: Ka Siu

Kommentare: 2

Schwierigkeitsgrad

Moderate

Schritte

Zeitaufwand

10 - 15 Minuten

Einleitung

This guide shows the procedures to replace a new keypad and clean metal button contacts for Nokia 6310i cell phone. Refer to the guides for removing the battery and separating the case from the motherboard.

Werkzeuge

Schritt 1

Press and hold the battery release button and slide the battery away from the Nokia logo

Schritt 2

Slide the SIM card lock away from the SIM card.
The SIM card pops out. Remove the SIM card.

Schritt 3

Unscrew and remove the four T6 Torx screws.

Needs updating with a picture with no SIM card.

Mustafa -

A comment for anyone wanting to clean the metal contacts to improve keypad response, make sure you spray iso alcohol onto a lint free cloth and wipe the contacts, not onto the device itself and definitely not onto the LCD screen, as it can leave a marl on the screen. Luckily it evaporated eventually but only after 48hrs...

John - 07/07/14

Schritt 4

Insert a plastic opening tool between the faceplate and the black backplate. Gently pry them apart, working from the lower end to the upper side of the phone.
