Einleitung
This 22 step guide to replace the Sony Cyber-Shot DSC-S90 flash is considered to be moderately difficult and take on average 30 minutes to complete. To reach the flash, a disassembly of the majority of the camera is required. This includes removing the battery terminal as well as the mother and daughter board which then gives the user the access to unclip the flash. The only tool needed is a J00 screwdriver.
-
-
Hold down the "open"button (gray oval with arrow pointing upwards) on the battery port door.
-
While holding the button downwards, slide the door upwards to unlock and open the door.
-
-
-
Remove the 2mm Phillips #00 screw under the battery port door.
-
Remove the 2mm Phillips #00 screw towards the right of the bottom-side of the camera.
-
-
-
Use an opening tool to unlock the front case from the main body of the camera. Use the tool on the right side and bottom of the camera with the LCD screen facing you.
-
-
-
Use an opening tool to unlock the front case from the main body of the camera. Use the tool on the top of the camera.
-
-
-
Release all clips and latches keeping the casing in place using a spudger, opening tool, or screwdriver.
-
-
-
Disconnect the ribbon cables on top of the battery terminal using a spudger or screwdriver.
-
-
-
Disconnect the remaining ribbon cable on the side of the camera using a spudger or screwdriver.
-
-
-
Once the battery terminal is unclipped, pull this ribbon cable out with a spudger or screwdriver to finish freeing the battery terminal.
-
-
-
Release the clips on either side of the connector/ribbon cable using a spudger or screwdriver.
-
-
-
Release the two clips next to the flash using a spudger or screwdriver.
-
Release the clip holding the LED indicator in place using a spudger or screwdriver.
-
Push the LED indicator upwards from below using a spudger or screwdriver.
-
To reassemble your device, follow these instructions in reverse order.
