This guide will help you in identifying the soldering joints locations for the loud speaker on the iPod Touch 4th Generation
Ersatzteile
-
-
I've boxed where the ribbon cable connectors go for the screen and camera.
-
The soldering joints are marked with a Blue and a Red dot to indicate where to solder the speaker wires.
-
The second picture shows the wires soldered to the logic board.
-
The loud speaker replacement was very tedious job.. anyways Good Luck
-
Abschluss
To reassemble your device, follow these instructions in reverse order.
