Werkzeuge

Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.

Troubleshooting

Follow this link to go to the troubleshooting page. We cover what steps to take if your battery does not hold a charge, your computer is plugged in but not charging, your trackpad is malfunctioning, your keyboard is malfunctioning, or if your Wi-Fi is spotty or refuses to connect.

Acer Spin 7 SP714-51 Troubleshooting

Background and Identification

The Acer Spin 7 SP714-51 is a 2-in-1 convertible laptop released by Acer in 2016. This laptop is an ultrathin and portable device for business and personal use, retailing when new for about $950. The Spin 7's construction is durable and the interior boasts an impressive touchpad and keyboard with a premium feel.

The model number can be located on the underside of the laptop on a black horizontal label. There are submodels of this laptop with different hardware configurations; to find your exact hardware configuration, note the last four digits of your model number: SP714-51-XXXX. Searching up this model number will let you know the exact hardware inside your configuration.

Technical Specifications

  • Screen: 1920 x 1080p, 14" Touchscreen
  • GPU: Intel HD Graphics 615 (Integrated)
  • CPU:
    • MO24, M4YD - Intel Kaby Lake Core i7-7Y75 CPU
    • MO9D – Intel Kaby Lake i5-7Y54

  • Ports: 2 x USB 3.1, mic/headphone
  • Operating System: Windows 10 Home
  • Storage: 256GB mSATA SSD
  • Memory: 8GB RAM
  • Battery Life: 8 Hours
  • Weight: 1.2Kg (2.64 lbs)
  • Size: 324 mm or 12.78” (w) x 229 mm or 9.04” (d) x 10.9 mm or 0.43” (h)

Additional Information
