Background and Identification

AsusTek Computer Inc produces a number of electronic devices including desktop computers, laptops, netbooks, mobile phones, networking equipment, etc. The brand ROG (Republic of Gamers) was established in 2006, which consists of a variety of computer hardware aimed towards gamers. The Asus Rog G75VX is a portable gaming laptop that is ‘built for battle’ with an Intel 3rd generation Core i7 processor, dual-fan cooling mechanism, and Nvidia 3D LightBoost technology.

The Asus Rog G75VX includes an illuminated keyboard and an indicator spot on the “w” key. The keyboard is sloped upward for wrist and hand comfort, and it has isolated arrow keys. The palm rest is a soft rubber/plastic. The ROG logo is located under the number pad in white, and the ASUS logo is located on the top of the laptop and under the display.

Technical Specifications

  • Processor: Intel® Core™ i7 3630QM Processor
  • Operating System: Windows 8
  • Chipset: Intel® HM77 Chipset
  • Memory: DDR3 1600 MHz SDRAM, 4 x SO-DIMM socket for expansion up to 32 GB SDRAM
  • Display: 17.3" Square HD+ EWV (1600 x 900)/Full HD (1920x1080)/Full HD 3D (1920x1080) LED Backlight
  • Graphic: NVIDIA® GeForce® GTX 670MX with 3GB GDDR5 VRAM
  • Storage:
    1. 2.5" SATA Dual HDD
    2. 1TB 5400
    3. 750GB 5400/7200
    4. 500GB 5400/7200
    5. 750GB 7200 SSH
    6. 256GB SSD
    7. RAID0/1 Support
  • Optical Drive:
    1. Blu-Ray DVD Combo
    2. Super-Multi DVD
    3. Blue-ray reader
  • Card Reader: 3 -in-1 card reader ( SD/ MS/ MMC)
  • Camera: HD Web Camera
  • Networking: Integrated 802.11 b/g/n or 802.11ac
    Built-in Bluetooth™ V4.0 (Optional)
    10/100/1000 Base T
    BT 4.0 support (on WLAN+ BT 4.0 combo card)
  • Interface:
  • 1 x Microphone-in jack
    1 x Headphone-out jack
    1 x VGA port/Mini D-sub 15-pin for external monitor
    4 x USB 3.0 port(s)
    1 x RJ45 LAN Jack for LAN insert
    1 x HDMI
    1 x SPIDIF speaker out
    1 x Thunderbolt port
  • Audio: Built-in Speakers And Microphone
    Built-in subwoofer
  • Battery: 8Cells 5200 mAh 74 Whrs
  • Power Adapter:
    1. Output :
      19 V DC, A, 180 W
      Input :
      100 -240 V AC, 50/60 Hz universal
  • Dimensions: 16.3 x 12.6 x 0.7 ~2.0 inch (WxDxH)
  • Weight: 9.9 lbs (with 8 cell battery)
  • Security: Kensington lock
