Base Cover
Werkzeuge
Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.
Background and Identification
The Precision 7510 is a high-end workstation laptop released by Dell in 2016. It has a 15.6-inch (39.6 cm) screen with a 1080p or 4K resolution, depending on your configuration. For computational power, the 7510 sports a 6th generation Intel Core processor or a server-grade Intel Xeon processor. With a design change from previous Dell Precision laptops, the 7510 has a black finish and a case made from dimpled carbon fiber and magnesium. You can identify this laptop by looking on the bottom case for a stick containing the model number “Precision 7510.” You can also find your service code (a.k.a. Dell serial number) here and use this to find more information on the Dell support website.
The Precision 7510 is highly repairable. Behind a battery cover on the bottom of the laptop you can access the hard drive bay and, of course, the replaceable battery. Removing the other half of the bottom panel gives you access to two memory slots, the wireless card, the cellular card, an M.2 SSD slot, and the coin cell battery which keeps power on to to hold the time and date. You can replace almost all parts of the computer including the speakers, right and left I/O boards, the display, the camera module, the keyboard, the heatsinks, and even the graphics card! If there is no guide for a particular component on iFixit, the 7510 manual (found on the product support page) has excellent documentation about the removal/installation process for each.
Technical Specifications
Processor
- 6th-generation Intel Core i5
- or 6th-generation Intel Core i7
- or Intel Xeon
Memory
- 4 SODIMM slots
- 64 GB maximum
- DDR4 memory
Storage
- 2.5-inch SATA III drive bay (maximum drive height of 9.5 mm)
- M.2 slot for an SSD (2280 form factor, M key)
Graphics
- AMD FirePro W5170M (2 GB GDDR5)
- or Nvidia Quadro M1000M (2 GB GDDR5)
- or Nvidia Quadro M2000M (4 GB GDDR5)
Display
- 15.6 inches (39.6 cm) on the diagonal
- 1920x1080 pixels or 3840x2160 pixels
- 60 Hz refresh rate
Connections
- Four USB 3.0 ports
- Optional USB-C port
- HDMI port
- Mini DisplayPort
- Gigabit Ethernet port
- 3.5 mm audio jack
- SD card reader
- Smart card slot
- Micro SIM card slot
Wireless
- Wi-Fi
- Bluetooth 4.0
- Cellular support (with SIM card)
Power
- 180 Watt AC power adapter (19.5 V, 9.23 A)
