Epson Home Cinema 1060 Repair

If you are having troubles with your Epson Home Cinema 1060, please refer to the troubleshooting page.

The Epson Home Cinema 1060 is a portable Full HD home theater projector with HDMI and MHL. Ideal for a variety of lighting conditions, the projector has high brightness. The device was released in August of 2017.

White plastic electronic projector. Lens on the front side with multiple ports and connections on the back. The top has many buttons to interact with and control the device with. There is a slider on the top as well to instantly block out the lens in case you need to stop showing something. There is also a slot on the side for a dust filter that can be replaced. You can find the model number on the text printed on the device itself or in the original packaging if you still have it!

Projection System:

3LCD, 3-chip technology

Projection Method:

Front / rear / ceiling mount

Driving Method:

Epson Poly-silicon TFT Active Matrix

Pixel Number:

2,073,600 dots (1920 x 1080) x 3

Color Brightness - Color Light Output:

3100 lumens2

White Brightness - White Light Output:

3100 lumens2

Aspect Ratio:

16:9 widescreen

Resolution:

Native 1080p (1920 x 1080)

Resize:

16:10, 4:3

Lamp Type:

210 W UHE

Lamp Life:

• ECO mode: Up to 7500 hours8
• Normal mode: Up to 4500 hours8

Throw Ratio Range:

1.02 – 1.23

Size - projected distance:

30" – 300"

Keystone Correction:

• ManualHorizontal: ±30 degrees
• AutomaticVertical: ±30 degrees

USB Plug 'n Play:

Projects audio and video, PC and Mac® compatible

Contrast Ratio:

Up to 15,000:1

Color Reproduction:

Up to 1.07 billion colors

Type:

Optical zoom/Manual focus

F-number:

1.58 – 1.70

Focal Length:

18.2 mm – 29.2 mm

Zoom Ratio:

Optical zoom 1.0 – 1.2
