HP Envy M6-1125dx Repair

The HP Envy M6-1125dx is a 15.6-inch laptop computer manufactured by Hewlett-Packard as part of the Envy family of devices. The M6-1125dx is part of the Envy M-series, which was originally called the Pavilion M-series. The HP Envy (stylized as HP ENVY) is a series of high-end laptops and other products produced and sold by Hewlett-Packard. The Envy line was launched in October 2009 with the Envy 12 and Envy 15. In 2012, HP discontinued the Envy 13, 14, 15, and 17 models by rebranding their Pavilion line of computers as the new Envy series. HP also has HP-branded desktops and printers with the Envy label.

The laptop includes a 15.6-inch high-definition display with a resolution of 1366 by 768 pixels. It has 750 GB of hard disk drive (HDD) storage and 8 GB of DDR3 SDRAM. The laptop includes a 62-Watt-hour six-cell lithium-ion battery and an Intel Core i5 (third-generation) processor.

The M6-1125dx model includes three USB 3.0 ports, one USB 2.0 port, an HDMI port, a VGA port, a LAN port, and a headphone/microphone combination jack. The laptop includes an SD card reader and a MultiMedia Card reader. It features a multi-touch keypad and brushed aluminum or natural silver body color.

GENERAL

• Recommended Use: home use
• Notebook type: Midsize, Budget, HD display
• Manufacturer: HP

PROCESSOR / CHIPSET

• CPU: Intel Core i5 (3rd Gen) 3230M / 2.6 GHz
• Max Turbo Speed: 3.2 GHz
• Number of Cores: Dual-Core
• Cache: L3 - 3 MB
• 64-bit Computing: Yes
• Features: Intel Turbo Boost Technology 2.0

CACHE MEMORY

• Type: L3 cache
• Installed Size: 3 MB

STORAGE

• Interface: Serial ATA-300
• Optical Drive: DVD±RW (±R DL) / DVD-RAM

RAM

• Technology: DDR3 SDRAM
• Installed Size: 8 GB

MEMORY

• Technology: DDR3 SDRAM
• Form Factor: SO-DIMM 204-pin
• Slots Qty: 2

DISPLAY

• LCD Backlight Technology: LED backlight
• Resolution: 1366 x 768 (HD)
• Widescreen Display: Yes
• Monitor Features: HD BrightView
• Type: LED
• Diagonal Size (metric): 39.6 cm
• Display Resolution Abbreviation: HD

AUDIO & VIDEO

• Graphics Processor: Intel HD Graphics 4000
• Total Available Graphics Memory: 1664 MB
• Integrated Webcam: Yes
• Sound: Stereo speakers, subwoofer, microphone
• Features: Beats Audio

HARD DRIVE

• Spindle Speed: 5400 rpm
• Type: HDD
• Capacity: 750 GB

INPUT

• Type: keyboard, touchpad
• Features: multi-touch board

COMMUNICATIONS

• Wireless Protocol: 802.11b/g/n
• Wired Protocol: Gigabit Ethernet

OPTICAL STORAGE

• Drive Type: DVD SuperMulti
• Type: DVD±RW (±R DL) / DVD-RAM

PROCESSOR

• CPU Type: Core i5
• Processor Number: i5-3230M
• Generation: 3
• Manufacturer: Intel
• Clock Speed: 2.6 GHz

CARD READER

• Type: card reader
• Supported Flash Memory: MultiMediaCard, SD Memory Card

BATTERY

• Capacity: 62 Wh
• Cells: 6-cell
• Technology: lithium ion

AC ADAPTER

• Output: 65 Watt

CONNECTIONS & EXPANSION

• Interfaces
  • 3 x USB 3.0
  • USB 2.0
  • HDMI
  • VGA
  • LAN
  • Headphone/microphone combo jack
• Memory Card Reader: Yes (SD Card, MultiMediaCard)

HEADER

• Brand: HP
• Product Line: HP Envy
• Model: m6-1225dx
• Localization: English
• Country Kits: United States
• Compatibility: PC

NETWORKING

• Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

MISCELLANEOUS

• Color: brushed aluminum, natural silver
• Features: HP 3D DriveGuard, power-on password, security lock slot (cable lock sold separately)

MONITOR

• Diagonal Size: 15.6 in

SOFTWARE

• Microsoft Office Preloaded: Includes a pre-loaded image of select Microsoft Office 2010 suites. Purchase an Office 2010 Product Key Card or disc to activate preloaded software on this PC.

SYSTEM

• Notebook Type: notebook
• Platform: Windows
• Hard Drive Capacity: 750 GB

DIMENSIONS & WEIGHT

• Width: 14.9 in
• Depth: 9.9 in
• Height: 1 in

ENVIRONMENTAL STANDARDS

• EPEAT Level: EPEAT Silver
• ENERGY STAR Certified: Yes

PHYSICAL CHARACTERISTICS

• Weight: 5.29 lbs

OPERATING SYSTEM / SOFTWARE

• OS Provided: Type: Windows 8 64-bit Edition
• Type: CyberLink PhotoDirector, CyberLink Power2Go, CyberLink PowerDirector, CyberLink YouCam DE, Cyberlink PowerDVD, HP Connected Music powered by Meridian, HP Connected Photo powered by Snapfish, HP Connected Remote, HP CoolSense, HP Games Powered by WildTangent, HP MyRoom, HP Recovery Manager, HP Registration, HP SimplePass, HP Support Assistant, HP+ Best Offers, Kindle e-reader, Mahjong, Netflix, Norton Internet Security (1 year subscription), Skype, Solitaire, Windows Live, Windows Store, ebay, iHeart Radio

VIDEO OUTPUT

• Graphics Processor: Intel HD Graphics 4000
• Graphics Processor Series: Intel HD Graphics

VIDEO MEMORY

• Total Available Graphics Memory: 1664 MB

NOTEBOOK CAMERA

• Integrated Webcam: Yes

INPUT DEVICE

• Numeric Keypad: Yes
• Backlight: Yes

SUSTAINABILITY

• Greenpeace policy rating (Nov 2011): 5.9
