Background and Identification

The HP Folio 13 is a 13-inch laptop introduced by HP. It was sold as a business-class thin Ultrabook for home use.

The HP Folio 13 runs on the Microsoft Windows 7 Professional 64-bit Edition operating system and features a Trusted Platform Module Security Chip. It is sold with an Intel Core i5 second-generation dual-core processor with a 3 MB cache and a Mobile Intel HM65 Express chipset. The HP Folio 13 includes 4 GB of RAM, though the computer can support up to 8 GB of RAM with one RAM slot. The laptop’s 13-inch display features an LED backlight and an HD BrightView glass cover that is larger than the viewable screen size. This model features 128 GB of solid-state drive (SSD) memory.

The HP Folio 13 is sold with a six-cell, 5-Watt-hour lithium-ion battery is advertised to have a run time of up to 9.5 hours. It includes an HDMI port, a headphone/microphone combination jack, a LAN port, a USB 2.0 port, and a USB 3.0 port. It also includes a memory card reader that is compatible with SD, MultiMedia, SDHC, and SDXC cards.

The HP Folio 13 includes “HP” printed in lowercase letters inside of a circle in the center of the computer’s bottom bezel. The computer’s trackpad is centered in its base.

Technical Specifications

GENERAL:

  • Recommended Use
  • home use
  • Embedded Security
  • Trusted Platform Module (TPM 1.2) Security Chip
  • Operating System
  • Microsoft Windows 7 Professional 64-bit Edition
  • Manufacturer
  • HP

PROCESSOR / CHIPSET:

  • CPU
  • Intel Core i5 (2nd Gen) 2467M / 1.6 GHz
  • Max Turbo Speed
  • 2.3 GHz
  • Number of Cores
  • Dual-Core
  • Cache
  • L3 - 3 MB
  • 64-bit Computing
  • Yes
  • Chipset Type
  • Mobile Intel HM65 Express
  • Features
  • Hyper-Threading Technology, Intel AES New Instructions (AES-NI), Intel Turbo Boost Technology 2.0

CACHE MEMORY:

  • Type
  • L3 cache
  • Installed Size
  • 3 MB

STORAGE:

  • Interface
  • Serial ATA-300

RAM:

  • Memory Speed
  • 1333 MHz
  • Memory Specification Compliance
  • PC3-10600
  • Configuration Features
  • 1 x 4 GB
  • Technology
  • DDR3 SDRAM
  • Installed Size
  • 4 GB
  • Rated Memory Speed
  • 1333 MHz

MEMORY:

  • Max Supported Size
  • 8 GB
  • Technology
  • DDR3 SDRAM
  • Speed
  • 1333 MHz / PC3-10600
  • Form Factor
  • SO-DIMM 204-pin
  • Slots Qty
  • 1
  • Empty Slots
  • 0

ENVIRONMENTAL PARAMETERS:

  • Humidity Range Operating
  • 10 - 95% (non-condensing)
  • Vibration Tolerance
  • 0.75 g @ RMS (random) (operating) / 1.5 g @ RMS (random) (non-operating)

DISPLAY:

  • LCD Backlight Technology
  • LED backlight
  • Widescreen Display
  • Yes
  • Image Aspect Ratio
  • 16:9
  • Monitor Features
  • HD BrightView, cover glass is bigger than viewable screen size
  • Type
  • LED
  • Diagonal Size (metric)
  • 33.8 cm
  • Display Resolution Abbreviation
  • HD

HARD DRIVE:

  • Type
  • SSD
  • Capacity
  • 128 GB

AUDIO & VIDEO:

  • Graphics Processor
  • Intel HD Graphics 3000
  • Memory Allocation Technology
  • Dynamic Video Memory Technology
  • Integrated Webcam
  • Yes
  • Sound
  • Stereo speakers, stereo microphone

INPUT:

  • Type
  • keyboard, touchpad
  • Features
  • backlighting, spill-resistant, volume control

COMMUNICATIONS:

  • Wireless Protocol
  • 802.11b/g/n, Bluetooth 2.1 EDR, Bluetooth 3.0 HS
  • Bluetooth Class
  • Class 1
  • Wireless Controller
  • Intel Centrino Wireless-N 1030
  • Wired Protocol
  • Gigabit Ethernet
  • Features
  • Intel Wireless Display (WiDi)

OPTICAL STORAGE:

  • Drive Type
  • no optical drive
  • Type
  • none

PROCESSOR:

  • CPU Type: Core i5
  • Processor Number: i5-2467M
  • Generation: 2
  • Manufacturer: Intel
  • Clock Speed: 1.6 GHz

CARD READER:

  • Type: card reader
  • Supported Flash Memory: MultiMediaCard, SD Memory Card, SDHC Memory Card, SDXC Memory Card

BATTERY:

  • Capacity: 59 Wh
  • Cells: 6-cell
  • Technology: lithium-ion
  • Run Time (Up To): 9.5 hour(s)

AC ADAPTER:

  • Input: AC 120/230 V (50/60 Hz)
  • Output: 65 Watt, 18.5 V, 3.5 A

CONNECTIONS & EXPANSION:

  • Interfaces
    • HDMI
    • Headphone/microphone combo jack
    • LAN
    • USB 2.0
    • USB 3.0
  • Memory Card Reader: Yes (SD Card, MultiMediaCard, SDHC Card, SDXC Card)

HEADER:

  • Brand: HP
  • Product Line: HP Folio 13
  • Localization: English
  • Country Kits: United States
  • Compatibility: PC

NETWORKING:

  • Data Link Protocol: Bluetooth 2.1 EDR, Bluetooth 3.0 HS, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
  • Compliant Standards: IEEE 802.1x, IEEE 802.3ab, Wi-Fi CERTIFIED
  • Wireless LAN Supported: Yes
  • Wireless NIC: Intel Centrino Wireless-N 1030

MISCELLANEOUS:

  • Security: Trusted Platform Module (TPM 1.2) Security Chip
  • Features: HP CoolSense, Intel Identity Protection Technology (Intel IPT), Intel Rapid Start Technology
  • Compliant Standards: ACPI, BSMI, C-Tick, CCC, CSA, FCC, GOST, ICES, KCC, MIC, SABS, UL, VCCI, WEEE
  • Included Accessories: power adapter
  • Manufacturer Selling Program: HP Smart Buy

MONITOR:

  • Diagonal Size: 13.3 in

SOFTWARE:

  • Microsoft Office Preloaded: Includes a pre-loaded image of select Microsoft Office 2010 suites. Purchase an Office 2010 Product Key Card or disc to activate preloaded software on this PC.

SYSTEM:

  • Notebook Type: Ultrabook
  • Platform: Windows
  • Hard Drive Capacity: 128 GB
  • Embedded Security: Trusted Platform Module (TPM 1.2) Security Chip

DIMENSIONS & WEIGHT:

  • Width: 12.6 in
  • Depth: 8.7 in
  • Height: 0.7 in

AUDIO OUTPUT:

  • Compliant Standards: Dolby Advanced Audio

MAINBOARD:

  • Chipset Type: Mobile Intel HM65 Express

ENVIRONMENTAL STANDARDS:

  • ENERGY STAR Certified: Yes

PHYSICAL CHARACTERISTICS:

  • Weight: 3.31 lbs

POWER:

  • Min Operating Temperature: 32 °F
  • Max Operating Temperature: 95 °F

OPERATING SYSTEM / SOFTWARE:

  • OS Provided: Type: Microsoft Windows 7 Professional 64-bit Edition
  • Type: Adobe Flash Player, HP Connection Manager 4.1, HP CoolSense, HP Quick Launch Button Software, HP Support Assistant, Microsoft Office 2010 Starter, Skype

VIDEO OUTPUT:

  • Graphics Processor: Intel HD Graphics 3000
  • Graphics Processor Series: Intel HD Graphics

VIDEO MEMORY:

  • Memory Allocation Technology: Dynamic Video Memory Technology

NOTEBOOK CAMERA:

  • Integrated Webcam: Yes

SERVICE & SUPPORT DETAILS:

  • Type: limited warranty
  • Service Included: parts and labor
  • Full Contract Period: 1 year
