Background and Identification

The Lenovo Thinkpad T430 was released in June 2012 as a less costly alternative to the premium-range Lenovo Thinkpad T430s. The T430 is a 14-inch Ultrabook that includes a third-generation Intel Core i5 processor. It was released as part of Lenovo's T Series mobile workstations and is marketed towards mainstream professionals. The ThinkPad T Series was introduced by IBM in 2000 but was transferred to Lenovo, a Chinese technology company, in 2005.

The Thinkpad T430 weighs approximately 4.8 pounds and includes a 57-Watt-hour nine-cell battery. It meets eight rugged military-specification tests against extreme environmental variables including temperature, pressure, dust, humidity, and vibration. Lenovo advertises that the T430 has up to 30 hours of battery life. The computer also includes a 720p HD webcam and dual digital array microphones, as well as stereo speakers. The Thinkpad T430 includes up to 16 GB of internal memory, a 3 GB cache, and 4 GB of RAM.

The Thinkpad T430 features an anti-glare LED (light-emitting diode) display and a carbon fiber case. It also includes a fingerprint reader that can be used as a password.

Lenovo ThinkPad T430 computers include the name "ThinkPad" in the lower right-hand corner of the laptop, underneath the keyboard at a 45-degree angle from the bottom edge of the device. It also includes the name "Lenovo" in lower-case letters in the bottom left-hand corner of the laptop's display.

Technical Specifications

General:

  • Platform Technology: Intel vPro Technology
  • Built-in Devices: ThinkLight
  • Embedded Security: Trusted Platform Module (TPM 1.2) Security Chip
  • Operating System: Microsoft Windows 7 Professional 64-bit Edition
  • Manufacturer: Lenovo

Processor/Chipset:

  • CPU: Intel Core i5 (3rd Gen) 3320M / 2.6 GHz
  • Max Turbo Speed: 3.3 GHz
  • Number of Cores: Dual-Core
  • Cache: 3 MB
  • 64-bit Computing: Yes
  • Chipset Type: Mobile Intel QM77 Express
  • Features: Hyper-Threading Technology, Intel Turbo Boost Technology 2.0, integrated memory controller

Storage:

  • Interface: Serial ATA-300
  • Optical Drive: DVD-Writer removable

RAM:

  • Memory Speed: 1600 MHz
  • Memory Specification Compliance: PC3-12800
  • Configuration Features: 1 x 4 GB
  • Technology: DDR3 SDRAM
  • Installed Size: 4 GB
  • Rated Memory Speed: 1600 MHz

Memory:

  • RAM: 4 GB (1 x 4 GB)
  • Max Supported Size: 16 GB
  • Technology: DDR3 SDRAM
  • Speed: 1600 MHz / PC3-12800
  • Form Factor: SO-DIMM 204-pin
  • Slots Qty: 2
  • Empty Slots: 1

Display:

  • LCD Backlight Technology: LED backlight
  • Widescreen Display: Yes
  • Image Aspect Ratio: 16:9
  • Monitor Features: anti-glare
  • Type: LED
  • Diagonal Size (metric): 35.5 cm
  • Display Resolution Abbreviation: HD

Audio and Video:

  • Graphics Processor: Intel HD Graphics 4000
  • Integrated Webcam: Yes
  • Capture Resolutions: 1280 x 720
  • Sound: Stereo speakers, stereo microphone
  • Audio Codec: Realtek ALC3202

Hard Drive:

  • Spindle Speed: 7200 rpm
  • Type: HDD
  • Capacity: 500 GB

Input:

  • Type: TrackPoint, UltraNav, keyboard
  • Features: multi-touch touchpad, spill-resistant, volume control

Communications:

  • Wireless Protocol: 802.11a/b/g/n, Bluetooth 4.0
  • Wireless Controller: Intel Centrino Advanced-N 6205 - PCI Express Mini Card
  • Wired Protocol: Gigabit Ethernet

Wireless Broadband (WWAN):

  • Generation: 3G upgradable

Optical Storage:

  • Drive Type: DVD-Writer
  • Type: DVD-Writer
  • Form Factor: removable

Processor:

  • CPU Type: Core i5
  • Processor Number: i5-3320M
  • Generation: 3
  • Manufacturer: Intel
  • Clock Speed: 2.6 GHz

Card Reader:

  • Type: 4 in 1 card reader
  • Supported Flash Memory: MultiMediaCard, SD Memory Card, SDHC Memory Card, SDXC Memory Card

Battery:

  • Capacity: 57 Wh
  • Cells: 6-cell
  • Technology: lithium-ion
  • Run Time (Up To): 9.7 hour(s)

AC Adapter:

  • Input: AC 120/230 V (50/60 Hz)
  • Output: 65 Watt

Connections and Expansion:

  • Expansion Bays: 1 x Ultrabay Enhanced
  • Slots: 1 x ExpressCard/34 (1 free)
  • Interfaces
    • USB 2.0
    • PoweredUSB 2.0
    • 2 x USB 3.0
    • VGA
    • Mini DisplayPort
    • LAN
    • Headphone/microphone combo jack
  • Memory Card Reader: 4 in 1 (SD Card, MultiMediaCard, SDHC Card, SDXC Card)

Header:

  • Brand: Lenovo
  • Product Line: Lenovo ThinkPad T430
  • Model: 2344
  • Compatibility: PC

Networking:

  • Data Link Protocol: Bluetooth 4.0, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
  • Interface (Bus) Type: PCI Express Mini Card
  • Ethernet Controller(s): Intel 82579LM
  • Wireless NIC: Intel Centrino Advanced-N 6205

Miscellaneous:

  • Case Material: carbon fiber, carbon fiber reinforced plastic, glass-fiber
  • Integrated Options: ThinkLight
  • Security: Trusted Platform Module (TPM 1.2) Security Chip, fingerprint reader
  • Features: Intel Active Management Technology (iAMT), Intel Small Business Advantage, ThinkPad Roll Cage, ThinkVantage Active Protection System, administrator password, hard drive password, power-on password
  • Compliant Standards: GREENGUARD, Nordic Ecolabel, RoHS
  • Included Accessories: power adapter
  • Manufacturer Selling Program: TopSeller
  • Theft/Intrusion Protection: Security lock slot (cable lock sold separately)
  • Security Slot Type: Kensington security slot

Monitor:

  • Diagonal Size: 14 in

System:

  • Platform Technology: Intel vPro Technology
  • Notebook Type: notebook
  • Platform: Windows
  • Hard Drive Capacity: 500 GB
  • Embedded Security: Trusted Platform Module (TPM 1.2) Security Chip
  • Security Devices: fingerprint reader

Dimensions and Weight:

  • Width: 13.4 in
  • Depth: 9.1 in
  • Height: 1.2 in
  • Weight: 4.78 lbs

Audio Output:

  • Compliant Standards: Dolby Advanced Audio v2, High Definition Audio

Mainboard:

  • Chipset Type: Mobile Intel QM77 Express

Environmental Standards:

  • EPEAT Level: EPEAT Gold
  • ENERGY STAR Certified: Yes
