Background and Identification

The OnePlus 3T (also known as the OP3T) Android smartphone is manufactured by OnePlus, a Chinese smartphone manufacturer. The OnePlus 3T was released in November 2016 as the successor to the OnePlus 3 smartphone, which was released in June 2016. The 3T was released in grey, gold, and black body colors. Only 250 black 3T phones were made from a partnership with Colette, a French fashion and accessory retailer. The black models feature a Colette logo on the back of the 3T.

The OnePlus 3T and 3 both include a scratch-resistant glass front and an aluminum back and frame. Both also feature dual-SIM capabilities, meaning the phone can operate on one SIM card while the second card is on stand-by. The phones are also the same size, each with a 5.5-inch display and 1080 by 1920 pixels. The OnePlus 3T was released with 6 GB of RAM and either 64 GB or 128 GB of internal storage. The 3 was only available with 64 GB of internal storage and 6 GB of RAM.

The OnePlus 3T includes a non-removable 3400 mAh battery with 20-Watt fast-charging capabilities. (A non-removable battery is one whose adhesive is permanent, making repair and replacement difficult). It also features a 16-megapixel main camera and selfie camera.

A TechRadar review found that the 3T has good battery life and performance, but did not have many upgrades when compared to the OnePlus 3 smartphone.

Technical Specifications

Models: A3010

Release date: November 2016

Body:

  • Dimensions and Weight: 152.7 x 74.7 x 7.4 mm (6.01 x 2.94 x 0.29 in), 158 g (5.57 oz)
  • Build: Glass front (Gorilla Glass 4), aluminum back, aluminum frame
  • SIM: Dual SIM (Nano-SIM, dual stand-by)

Display:

  • Type: Optic AMOLED capacitive touchscreen, 16M colors
  • Size: 5.5 inches, 83.4 cm2 (~73.1% screen-to-body ratio)
  • Resolution: 1080 x 1920 pixels, 16:9 ratio (~401 ppi density)
  • Protection: Corning Gorilla Glass 4

Platform:

  • OS: Android 6.0.1 (Marshmallow), upgradable to Android 9.0 (Pie)
  • Chipset: Qualcomm MSM8996 Snapdragon 821 (14 nm)
  • CPU: Quad-core (2x2.35 GHz Kryo & 2x1.6 GHz Kryo)
  • GPU: Adreno 530

Memory:

  • Card slot: No
  • Internal: 64GB 6GB RAM, 128GB 6GB RAM

Main Camera:

  • Single: 16 MP, f/2.0, 1/2.8", 1.12µm, PDAF, OIS
  • Features: LED flash, panorama, HDR
  • Video: 4K@30fps, 1080p@30/60fps, 720p@120fps, Auto HDR

Selfie Camera:

  • Single: 16 MP, f/2.0, (wide), 1/3.06", 1.0µm
  • Video: 1080p@30fps

Sound:

  • Loudspeaker: yes
  • 3.5 mm jack: yes

Communications:

  • WLAN: Wi-Fi 802.11 a/b/g/n/ac, Wi-Fi Direct, DLNA, hotspot
  • Bluetooth: 4.2, A2DP, aptX HD, LE
  • GPS: Yes, with A-GPS, GLONASS, BDS
  • NFC: Yes
  • Radio: No
  • USB: 2.0, Type-C 1.0 reversible connector

Features:

  • Sensors: Fingerprint (side-mounted), accelerometer, gyro, proximity, compass

Battery:

  • Non-removable Li-Ion 3400 mAh battery
  • Charging:
    • Fast charging 20W
    • Dash Charge

Miscellaneous:

  • Colors: Gunmetal, Soft Gold, Midnight Black
  • SAR: 0.99 W/kg (head)     0.65 W/kg (body)
