Power Transformer
Technical Specifications
Picture/Display
•Aspect ratio: Widescreen
•Brightness: 300 cd/m²
•Contrast ratio (typical): 800:1
•Response time (typical): 5 ms
•Viewing angle: 170º (H) / 160º (V)
•Diagonal screen size: 22 inch / 56 cm
•Visible screen diagonal (inch): 21.6 inch
•Panel resolution: 1366 x 768p
Connectivity
•AV 1: Audio L/R in, YPbPr
•Front / Side connections: HDMI v1.3, S-video in, CVBS in, Audio L/R in, Headphone Out, USB
•Audio Output - Digital: Coaxial (cinch)
•Other connections: PC Audio in, PC-In VGA
•HDMI 1: HDMI v1.3, Analog audio L/R in
•EasyLink (HDMI-CEC): One touch play, Power status, System info (menu language), System audio control, System standby
Power
•Ambient temperature: 5 °C to 35 °C
•Mains power: 120V/60Hz
•Power consumption: 70 W
•Standby power consumption: < 0.5 W
Dimensions
•Set dimensions in inch (W x H x D): 21.6 x 14.8 x 3.5 inch
•Set dimensions with stand in inch (W x H x D): 21.6 x 16.3 x 7.1 inch
•Product weight (+stand) (lb): 10.9 lb
•VESA wall mount compatible: 100 x 100 mm
