Background
The Philips Respironics Esprit Ventilator is a respiratory life-support device made by the company Philips. The Esprit was released in the 2000’s when Philips transitioned from making household products to modern healthcare devices. While no longer sold on the Philips website, the Esprit is still available online through medical retailers.
The Esprit ventilator provides invasive and non-invasive ventilation for hospital patients of all ages. This ventilator is microprocessor driven and offers continuous or intermittent ventilation. The ventilator contains no air compressor, allowing it to run on either AC power, external battery, or battery pack.
The Esprit also includes the Auto-Trak algorithm, which uses sensors that automatically adjust to a patient’s breathing patterns and dynamic leaks. The device offers breath type options for Volume Control Ventilation (VCV), Pressure Control Volume (PCV), Non-Invasive Positive Pressure Ventilation (NPPV), and Apnea Ventilation.
Features of the Esprit include a full-color touch screen, standard breathing circuit and filters, prioritized alarms, and a variety of graphics that indicate a patient’s condition.
Philips ventilators have undergone a series of recalls for devices made between 2009 and 2021. The FDA recommends registering any Respironics devices on the Philips Respironics recall website.
Identification
The Philips Respironics Esprit Ventilator has a box-like appearance and the option to attach a rolling stand to the bottom of the device. The product number, serial number, bar code, model type, and manufactured year can be found on a white sticker at the base of the device.
Technical Specifications
Ventilator Dimensions:
- Height: 16 in (40 cm)
- Width: 14 in (36 cm)
- Depth: 24 in (61 cm)
- Weight: 66 lbs. (30 kg)
- Display Unit: 10.4 in (26.4 cm)
Interface Ports:
- Parallel Printer Port
- RS-232 Output and Input
- Analog Output 0-5
- VDC Full-Scale
- Remote Alarm Nurse Call
- Remove Alarm Annunciation
Breath Types:
- Volume Controlled Ventilation (VCV)
- Pressure Controlled Ventilation (PCV)
- Non-Invasive Positive Pressure Ventilation (NPPV)
- Apnea Ventilation
Modes:
- Assist/Control (A/C): VCV, PCV
- SIMV: VCV, PCV
- Spont/T: NPPV
- Spont: NPPV
Alarms:
- Apnea Alarm Time: 10-60 seconds
- Alarm Silence: 120 seconds
- Adjustable Audible Alarm Volume: 54-77 dB
- High Inspiratory Pressure: 10-105 cm H2O
- Low Inspiratory Pressure: 3-105 cm H2O
- High Respiratory Rate: 0-150 bpm
- Expiratory Tidal Volume: Low Mandatory (0-2500 mL), Low Spontaneous (0-2500 mL)
Volume Ventilation Controls:
- Respiratory Rate: 1-80 bpm
- Plateau: 0-2 seconds
- Tidal Volume: 50-2500 ml
- Peak Inhalation Flow: 3-140 lpm
- PEEP: 0-35 cm H2O
- PSV Pressure: 0-35 cm H2O
- Pressure Sensitivity: (-20)-(-0.1) cm H2O (hPA)
- Flow Sensitivity: 0.5-20 lpm
- Exhalation Trigger: 10%-45% of inspiratory peak flow
- Rise Time: 0.1-0.9 seconds
- Oxygen percentage: 21%-100%
- Inspiratory Hold: 0-2.0 seconds
- Flow Waveform: Descending ramp, square
- Apnea Rate: 1-80 bpm
- Patient Type: Adult/Pediatric
Pressure Controls:
- Respiratory Rate: 1-80 bpm
- PCV Pressure: 5-100 cm H2O (hPa)
- Inhalation Time: 0.1-9.9 seconds
- PEEP: 0-35 cm H2O
- PSV Pressure: 0-100 cm H2O
- Flow Sensitivity: 0.5-20 lpm
- Exhalation Trigger: 10%-45% of inspiratory peak flow
- Rise Time: 0.1-0.9 seconds
- Oxygen Percentage: 21%-100%
- Apnea Rate: 1-80 bpm
- Patient Type: Adult/Pediatric
Non-Invasive Controls:
- Respiratory Rate: 1-80 bpm
- EPAP: 2-25 cm H2O (hPa)
- IPAP: 2-25 cm H2O (hPa)
- Inhalation Time: 0.1-9.9 seconds
- Rise Time: 0.1-9.9 seconds
- Flow Sensitivity: 0.5-20 lpm from base flow (3 lpm above sensitivity)
- Exhalation Trigger: 10-45% of inspiratory peak flow
- Oxygen Percentage: 21%-100%
- Apnea Rate: 1-80 bpm
- Patient Type: Adult/Pediatric
