Background and Identification

The Sony Cyber-shot DSC-TX100V is an ultra compact camera that has a 1/2.3" CMOS sensor and 4x optical zoom. It takes 16.2 megapixel shots and has a 25-100 mm equivalent range. The front of the camera uses a sliding door mechanism to cover the lens, and the back of the camera is covered by a 3.5 inch OLED touchscreen.

Specifications

Camera

  • Resolution: 16.2 MP, 15.9 MP effective (4608 x 3456 pixels)
  • Sensor: 1/2.3" Exmor R CMOS
  • Lens: Carl Zeiss 4x optical zoom (25-100 mm equivalent)

Display

  • Resolution: 1.23 million dots
  • Panel: 3.5 inch OLED

Design

  • Dimensions: 3.8 x 2.3 x 0.7 inch
  • Weight: 5.2 oz.

Connectivity

  • USB 2.0
  • Sony Multi-connector
  • HDMI type-C

Additional Information
