Background and Identification

Released in October 2012 in China, the Xiaomi Mi 2 is an Android smartphone featuring a quad-core 1.5 GHz Qualcomm Snapdragon S4 Pro as its CPU. The phone is made mostly from plastic and has SIM card slots located inside. The microUSB can be found at the bottom of the device and the audio jack can be found at the top of the device. As for the power and volume keys, those controls are located at the right side of the device. Users can find the front-facing camera (2 megapixels) at the top of the phone. Moreover, the Xiaomi Mi 2 has proximity sensors located at the top of the phone which sense whether the phone is in a pocket or not. Available in white, green, yellow, blue, red, and pink, the Xiaomi Mi 2 caters to a wide audience and has a 4.3 inch display, larger than its predecessor.

Technical Specifications

  • Manufacturer: Xiaomi
  • Series: Xiaomi Phone
  • Compatible networks: GSM 850,900,1800,and 1900MHz & WCDMA 850, 1900 and 2100MHz
  • Availability by Region: China October 12
  • Predecessor: Xiaomi Mi 1S
  • Successor: Xiaomi Mi 2A, Xiaomi Mi 2S
  • Type: Smartphone
  • Dimensions;
    • Height: 125 mm (4.9 in)
    • Width: 62 mm (2.4 in)
    • Depth: 10.2 mm (0.40 in)
  • Mass: 145 g (5.1 oz)
  • Operating System:
    • Original: MIUI V4 (Android 4.1 Jelly Bean)
    • Current: MIUI 9 (Android 5.0.1 Lollipop)
  • CPU: Qualcomm Snapdragon S4 APQ8064 Quad-Core Krait @ 1.5 GHz
  • GPU: Adreno 320
  • Memory: 2GB RAM
  • Storage: 16GB/32GB ROM
  • Removable Storage: None
  • Battery: 1930 mAh, 3100 mAh (optional)
  • Data Inputs: Capacitive touch screen
  • Display: IPS Display 4.3 inches @ 1280px x 720px (341 PPI) (Manufactured by Sharp Inc.)
  • Rear Camera: 8 Megapixels (backside-illuminated (BSI)), Records 1080p at 30fps and 720p at 90 fps
  • Front Camera: 2 Megapixels, 1080p at 30fps
  • Connectivity:
    • Bluetooth 4.0 + A2DP
    • Wi-Fi (802.11 b/g/n)
    • Wi-Fi Direct
    • Micro-USB On-The-Go with MHL link
    • DLNA
