Back Panel
Werkzeuge
Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.
Troubleshooting
For additional help with your ZD-N Plus Wireless Controller go to the ZD-N Plus Wireless Controller Troubleshooting guide.
Background And Identification
The ZD-N Plus Wireless Controller model ZD-N208 is a wireless gaming controller that has the option to connect to multiple platforms including PC (Windows 7 / 8 / 8.1 / 10), Nintendo Switch, Android Tablet, or Android TV Box. The controller is designed to enable wireless connectability to ensure an easy and comfortable gaming experience.
The controller weighs 210 grams and makes usage of an ergonomic design that eliminates strain on the hands, allowing for a pleasant experience. It has a plastic exterior that comes in either black, red, or blue. The controller features dual analog sticks, a directional pad, input (ABXY) buttons, dual triggers, bumpers, and menu buttons on the face of the controller. It contains a single, built-in rechargeable lithium polymer battery.
The controller also features USB 2.0/3.0 connectability and wireless USB dongle.
Note: Some platforms require specific software for the controller to function properly. In order to use the controller on a Windows 10 operating system, the user will need to install DirectX 9.0 or above. For any Windows operating system the controller requires installation of the Xbox 360 Controller Official driver. For an Android OS the device must be capable of supporting the OTG function.
The model number and device number of the controller can be found on the back of the box that the ZD-N Plus Wireless Controller comes in, as well as on the owner manual packaged with the device.
Specifications
Model - ZD-N208S
Product Size - 156X100X57mm
Temperature - 10C-+60C
Agreement - 2.4GHz Wireless
Working mode - Switch/Xinput/Android
Buttons - START button, BACK button, Directional buttons (Up/Down/Left/Right), Action buttons (Y,B,A,X), LB/RB/LT/RT, Right stick, Left stick
