OnePlus 6T Teardown

Geschrieben von: Michael Degnan
Veröffentlicht: 13/11/18
  • Kommentare: 13

OnePlus 6T Teardown

Veröffentlicht: 13/11/18

Teardown

Einleitung

  1. UQdnVjPPSl4dRCwm

    • Nach dem Öffnen des Smartphones, kann der Akku gleich entfernt werden. Er ist nur leicht verklebt und verfügt über eine Zuglasche zum einfachen Entfernen.

    • Viele Komponenten sind modular aufgebaut und können einzeln ausgetauscht werden.

    • Alle Gewindebefestigungen sind standardmäßige Kreuzschlitzvarianten.

    • Der Austausch des Displays, was eine häufige Reparatur ist, ist vom Design her keine Priorität. (Du musst das Handy komplett zerlegen, um deinen Bildschirm auszutauschen.)

    • Glas auf der Vorder- und der Rückseite bedeutetet doppeltes Risiko, dass etwas zerbricht, und das ohne den Vorteil des kabellosen Ladens.

    • Der primäre Zugangspunkt für alle Reparaturen, nämlich die Rückabdeckung, ist fest verklebt.

Tinte & Feder

Michael Degnan

13079 Reputation

13 Kommentare

How much does it cost to replace the screen on the Oneplus 6T?

Chen Ray -

€ 91,00 for the screen. Unclear the repair cost https://www.oneplus.com/uk/support/repai....

Screen less than half the cost of the Samsung s9. Key reason I bought this phone.

Andy Woods -

Where is the full report with picture of the board and components? (like the one on pixel3)

Javad Hadi -

Yeah… I notice the full reports are not a thing anymore… Bring them back, please.

Philippe Morin -

I will try to make a full teardown of this OnePlus 6T (On my personal phone)

Matthew Kellett -

Is ther any update on a full teardown guide for the 6T? Also, is anyone going to upload any xray/circuitboard photos of this phone? I would be very interested if anyone would be willing to do so.

jeff floyd -

Which is that background music used in the OnePlus 6t teardown video on YouTube?

Superb Stupid -

Can you post OnePlus 6T teardown wallpaper please?

Thank you!

Carlos Herrera -

Teardown wallpaper please

Daniel G -

I have new Display but Fingerprint Not Work

I need help

Mohamed Ali Younes -

If you attempt to just do a screen replacement extreme caution must be taken not to remove the plastic band surrounding the screen. IT lies between the screen and metal frame. It is very easy to peal screen with the plastic frame attached. Once done you will have no choice but to buy a new housing with the screen built in and swap components. It is also very easy to damage/nick the aluminum housing when removing the screen. Honestly, getting a new screen with the housing already attached is your easiest and safest option in my opinion. Just make sure the new part you ordered has all the switches and various camera shields/seals installed. If not carefully swap them from your old housing. The one I rebuilt was missing the power button on the new housing. I found this out once I had it all back together and couldn’t power up the phone. Finally, caution with the white cable connection up on the mother board. The ring that cable clips on to in the board is easily damaged. Take your time clipping it on.

Tracey -

I've had a problem with that white cable you mention at the end, could you tell me exactly what it does and where I can buy it? I have been looking in several places but I can only find black coaxial cable and this one is white. Thank you very much!!!!

VICTOR ALVAREZ -

I have replaced the battery of my Oneplus 6t with a minor damage.

I just cut the white “antenna cable”, but i’m not sure about the real name of it.

Does anyone know the real specs of that cable?

I’m looking for it on aliexpress but i’m not finding any white cable, only black or with stripes.

Patrick -
