Background and Identification

The Apple AirPods were announced in September of 2016 alongside the iPhone 7. The headphones communicate wirelessly (conveniently, as the iPhone 7 does not have a headphone jack) using Bluetooth technology. In addition to existing Bluetooth protocol, Apple has introduced the W1 chip into the AirPods, purportedly enhancing wireless connectivity for a better connection and improved sound.

Specifications

Weight:

  • AirPods (each) - 0.14 ounces (4g)
  • Charging Case (each) - 1.34 ounces (34g)

Dimensions:

  • AirPods (each) - 0.65 by 0.71 by 1.59 inches (16.5 by 18.0 by 40.5 mm)
  • Charging Case - 1.74 by 0.84 by 2.11 inches (44.3 by 21.3 by 53.5 mm)

Connectivity:

  • AirPods - Bluetooth
  • Charging Case - Lightning connector

Sensors:

  • Dual beam-forming microphones
  • Dual optical sensors
  • Motion-detecting accelerometer
  • Speech-detecting accelerometer
