These are some common tools used to work on this device. You might not need every tool for every procedure.
Background and Identification
The Karcher Puzzi 50/14 E is a 200 PSI box-and-wand portable carpet extractor with a 1,850-Watt internal water heater for additional cleaning power. It is sometimes identified by its order number, 1.006-673.0. It is manufactured and sold by Alfred Kärcher SE & Co. KG, a family-owned business that sells cleaning equipment and systems.
The Karcher Puzzi 50/14 E includes an adjustable spray pressure between 0 and 200 PSI that allows users to clean delicate upholstery and dirty carpets. It also features 12-inch wheels that allow users to more easily maneuver the cleaner. The Karcher Puzzi 50/14 E includes a 13-gallon solution tank and an 11-gallon recovery tank. A 17-gallon capacity solution tank is also available from Karcher. The 17-gallon version has an adjustable spray between 0 and 500 PSI. It comes with two power cords and the hose and wand attachments are optional. The carpet cleaner also has a pressure gauge for user safety.
The Karcher Puzzi 50/14 E’s machine controls are located on the front panel of the cleaner. The machine is made of rotationally molded polyethylene tanks. The name “Karcher” is printed in capital letters on the side of the carpet cleaner and underlined with a yellow stripe. The cleaner’s main body is black but the handle and part of the cleaner’s top half is grey plastic.
Technical Specifications
Solution capacity (gal): 13
Recovery capacity (gal): 11
Pump (psi): 500/200
Water lift in H2O (standard/heat) (in): 107/74
Air flow: (standard/heat) (cfm): 73/111
Heater (w/ heat only) (W): 1850
Weight (standard/heat) (lbs): 115/134
Dimensions (L x W x H) (in): 30.5 x 22 x 43.25
