Back Panel
Tools
These are some common tools used to work on this device. You might not need every tool for every procedure.
Troubleshooting
If you are not sure what is wrong with the Sony Vaio VGN-NW240F, head over to the troubleshooting guide.
Background and Identification
To identify if the model of your Sony VAIO is VGN-NW240F you have, check the bottom left of the display for the model number. The laptop was released in 2009, but is not currently being sold actively by retailers.
The Sony VAIO VGN-NW240F (PCG-7184L) Laptop Computer comes with Windows 7 Home Premium 64-bit operating system and a 320GB Serial ATA hard disk drive. Graphics are displayed on a 15.5-inch diagonal widescreen HD-capable display with a 1366x768 resolution. It has a HD Display with a HDMI port, and runs an integrated Intel Graphics Media Accelerator 4500MHD with Intel Clear Video Technology with 1750MB Total Available Graphics Memory. The Sony VAIO VGN-NW240F has an onboard Ethernet and 802.11b/g/n wireless card. The Sony VAIO VGN-NW240F Laptop Computer also features an integrated webcam and microphone with face-tracking technology, DVDRW optical drive, and media card reader.
PCG Reference : PCG-7184L
Model number : VGN-NW240F
Specification
Colors
- Brown
- White
- Black
- Silver
- Pink
Display
- Screen size: 15.5"
- Resolution: 1366 x 768
Item Weight
- 6 pounds
Item Dimensions L x W x H
- 9.80 x 14.60 x 1.20 inches
Operating System
- Windows 7 Home Premium 64-bit
Processor
- 2.2 GHz Intel Core 2 Duo
Memory
- 4 GB (2x2) DDR2 at 800MHz
- Maximum 8GB
Hard Drive
- 320 GB at 5400RPM
- Serial ATA
Graphics
- Processor: Mobile Intel® Graphics Media Accelerator
4500MHD with Intel® Clear Video Technology
- Total Available Graphics Memory: 1750MB
- Chipset: Intel® GM45 Express Chipset
Camera
- Built-in MOTION EYE® camera and microphone with face-tracking technology
Input and Output
- Headphone Jack: 1
- Microphone Input: 1
- USB Port(s): 3 (2.0 compliant)
- VGA Output(s): 1
- Ethernet Connection (s): 1
- HDMI™ Output(s): 1
Average Battery Life (in hours)
- 4 hours
Battery Type
- Lithium_Ion
Power Source
- AC
Additional Information
For more information, please visit the following links:
Sony eSupport VAIO Notebook Computer
