Processor
type : Intel® Atom™ processor N270
clock speed : 1.60 GHz
Front Side Bus : 533 MHz
2nd level cache : 512 KB
Operating System / Platform
Windows® XP Home Edition (Toshiba-Recovery DVD)
Design Colour
colour : Gold
System memory
standard : 1,024 MB
maximum expandability : 1,024 MB
technology : DDR2 RAM (667 MHz)
Hard disk
capacity : 120 GB
certification : S.M.A.R.T.
drive rotation : 5,400 rpm
Display
size : 8.9 "
type : Toshiba TruBrite® WSVGA TFT display with LED backlight
internal resolution : 1,024 x 600
Graphics adaptor
type : Mobile Intel® GMA 950
memory amount : up to 224 MB total available graphics memory with 512 MB system memory
memory type : shared
Internal video modes
The following internal video modes are supported :
resolution : 1,024 x 600
Max External Video Modes
Max Resolution : 2,048 x 1,536
Max Refresh Rate : 120 Hz
Non-interlaced resolution with max refresh rate : 1,600 x 1,200
Interfaces
1 × 4-in-1 Bridge Media slot (supports SD™ Cards up to 16 GB, Memory Stick® up to 256 MB, Memory Stick Pro™ up to 2 GB and MultiMedia Card™ up to 2 GB)
1 × built-in microphone
1 × DC-in
1 × external microphone
1 × external monitor
1 × headphone (stereo)
1 × RJ-45
3 (Left 1, Right 2) × USB 2.0 Sleep-and-Charge
1 × integrated VGA Web Camera
Expansion
1 × memory slot
Wired communication
topology : Fast Ethernet LAN
speed : 10BASE-T/100BASE-TX
Sound system
manufacturer : Toshiba Bass Enhanced Sound System
supported audio format : 24-bit stereo
speakers : built-in stereo speakers
Keyboard
keys : 80
Windows keys : Yes
Pointing device
type : Touch Pad
Battery
technology : lithium-ion
maximum life : up to 3h50min (Mobile Mark™ 2007)
AC adaptor
input voltage : autosensing AC adapter (100/240 V) for worldwide usage
output voltage : 19 V
output current : 3.42 A
Physical dimensions
W x D x H : 225 x 190.5 x 29.5 (front) / 33 (rear) mm
weight : starting at 0.999 kg
Warranty
1-year international warranty. Upgrade your standard warranty with dynabook warranty extension, uplift and all-risks insurance packs.
Bundled hardware
AC adaptor
Bundled software
Connectivity Doctor
McAfee® Internet Security Suite - Toshiba Edition (includes free Internet updates for 30 days)
Microsoft® Works, Microsoft® Office Home and Student 2007 (free 60-day trial)
Chicony Camera Assistant Software
ConfigFree™
Toshiba DVD Player
Toshiba Disc Creator
Toshiba User's Manual
Toshiba utilities and drivers
Toshiba EasyMedia
Built-in camera & microphone
Diversity Antenna
Integrated Bridge Media Adapter
McAfee® Internet Security Suite - Toshiba Edition
Smart Display Support
Toshiba ConfigFree™
USB Sleep-and-Charge
Security features
user password
supervisor password
HDD password on request
main memory (by screw)
main hard disk (by screw)
main battery pack (by sliding latch)
slot for Kensington Cable Lock
Special features
ENERGY STAR qualified computer
Enhanced Intel® SpeedStep® Technology
HD Audio support
SM BIOS compliant
integrated VGA Web Camera for Video over IP
integrated microphone for Voice over IP
Certification
The manufacturer declares that this product complies with the following directives and regulations for the CE-marking. Responsible for CE marking is Dynabook Europe GmbH, Stresemannallee 4b, 41460 Neuss, Germany.
