Background and Identification

At first glance, it would seem that there’s very little a manufacturer can do these days to make its 10-inch netbook stand out from the hordes of others on the market. Yet, despite being more than a year late to the game in North America, Toshiba’s mini NB205 does just that. It has created a netbook that, while housing a standard Intel Atom processor, 1GB of RAM, and Microsoft Windows XP Home, manages to break the mold. With a beautiful chassis, a spacious keyboard and touchpad, an exemplary more-than 9 hours of battery life, and a competitive $399 price tag, Toshiba’s netbook rises above the competition.

Specifications

Processor: 1.66GHz Intel® Atom™ Processor N280

Operating System: Genuine Windows 7 Starter Edition 32-bit

Memory Size:

  • 1GB DDR2 533MHz
  • 2GB Maximum

Display: 10.1" (1024 x 600) WSVGA diagonal LED backlight widescreen display

Graphics Engine: Intel® Graphics Media Accelerator GMA950

Graphics Memory: 64MB-251MB dynamically allocated shared graphics memory

Hard Drive: 250GB (5400 RPM) Serial ATA hard disk drive

Optical Drives: Sold Separately: Toshiba Portable USB DVD SuperMulti Drive

Webcam: Webcam and microphone built into LCD bezel

Wireless LAN: Atheros® Wireless LAN (802.11b/g)

Bluetooth: Bluetooth® V2.1 + EDR

Inputs and Controls: 85 key US keyboard, TouchPad™ pointing device

Security and Protection: Security Cable Lock Slot, HDD Recovery

LAN: 10/100 Ethernet LAN

Audio: Headphone jack (stereo), Microphone jack (mono), Built-in monaural speaker

AC Adapter: 30W (19V 1.58A) Auto-sensing, 100-240V / 50-60Hz input

Battery: Li-Ion (5800mAh, 6-Cell)

Battery Life: Up to 9.08 hours

Media: Memory Card Reader

Ports:

  • Video: RGB (monitor) output port
  • Audio:
    • Microphone input port
    • Headphone output port
  • Data:
    • 3 USB v2.0 ports
      • Left side port with USB Sleep and Charge
    • RJ-45 LAN port
  • Security: Slot for Security Lock

Approximate Dimensions:

  • Height: 1" - 1.27"
  • Width: 10.4"
  • Depth: 8.3"

Approximate Weight: 2.93 lbs

Warranty Information

Manufacturer Warranty (authorized online retailer): One Year Parts and Labor

Troubleshooting

If you are experiencing difficulties with your netbook, diagnostic information is located here:

Toshiba NB205 N330PK Troubleshooting

Additional Information

Toshiba Support

Toshiba Support Community Forums

User Guide for the NB205-N330PK

Toshiba Support User Guide for NB205-N330PK
