Motorola Moto G7 Play Speaker Replacement

Geschrieben von: curt caudle

Kommentare: 4

Motorola Moto G7 Play Speaker Replacement

Schwierigkeitsgrad

Moderate

Schritte

Zeitaufwand

15 - 25 Minuten

Einleitung

This guide will show each detailed step to removing and replacing the speaker inside Motorola G7 Play, model number XT1952-3 or XT1952-2. The speaker is used for phone calls and playing sound on the phone. If the phone no longer plays audio correctly or doesn’t have any audio the speaker will need to be replace.

Werkzeuge

Schritt 1

Turn off your device before you begin.
Use the iFixit pick to break the adhesive around the back case.
Use a heat gun, hairdryer, or iOpener to weaken the adhesive around the back case. If you're using the iOpener, please review the instructions for proper use.

How long do you have to use the heat gun before the glue loosens?

Pamela DeMars -

It's worked for me with about maybe 15-20 seconds of heating per side.

Matthieu Bister -

Schritt 2

Detach the back case from the phone.
Make sure the back is opened right to left so the cable of the fingerprint scanner does not get damaged.

Schritt 3

Use the iFixit pick and the iFixit opening tool to pull the fingerprint scanner off of the back case.

Schritt 4

Remove the nine 3.2mm screws from the motherboard cover with a Phillips #00 screwdriver.

Schritt 5

Lift motherboard cover off by the bottom.
Use reverse tweezers or a similar tool if needed.

Schritt 6

Once the motherboard cover is removed, disconnect the four ribbon cables and the two wires attached to the motherboard.

Schritt 7

Using the Phillips #00 screwdriver, remove the single 0.4 mm black screw in the center of the motherboard.
Remove the motherboard from the device.

Please add more photos or explain more thoroughly how exactly to remove the motherboard at this stage. (e.g. from top or bottom or left/right, using a flat screwdriver,etc).

Amy -

I struggled at this step too. The Battery Replacement guide starts with a crucial step that's missing in this current guide: removing the SIM card.

Motorola Moto G7 Play Battery Replacement - iFixit Repair Guide

Matthieu Bister - 23/08/22
