Teddy Ruxpin Speaker Replacement

Geschrieben von: Jayin Patel

Kommentare: 2

Schwierigkeitsgrad

Moderate

Schritte

Zeitaufwand

1 Stunde

Einleitung

This guide will help you resolve any problem with your speaker on your Teddy Ruxpin model #17262DS. If the volume, sound quality, or general audio qualities of your bear are lacking this guide should help you fix those issues. A Phillips #1 screwdriver is required to complete this guide. Desoldering is also required so be sure to look at the desoldering guide for help.

Werkzeuge

Schritt 1

Remove the vest covering the back of the bear.
Orient the bear with his back facing upwards and unscrew the single Phillips #2 screw.
Captured screws will stay in place, no need to worry about losing this one!

If screw is missing could this be the problem

nursejackie55 -

Schritt 2

Pull the tab outward to remove the protective plate for the batteries.

Schritt 3

Remove all four AA batteries by pushing the positive end down and pulling the battery out toward yourself.

I have already changed out the batteries and it still want com on.

Wendy Nickel

breezy_bear99 -

Schritt 4

Cut the orange shirt and zip tie.
Remove the zip tie.

Schritt 5

Cut across the back seam of the head of the bear along the arrow.
This damages the bear's exterior and will require resewing.

Schritt 6

Remove the interior of the doll.
Peel the outer layer around the head of the bear and forcefully pry off the face of the bear from the outside layer of the bear.
This will be difficult and require significant force, but do not fear about breaking the doll at this stage.
