iPad 2 Wi-Fi EMC 2560 Headphone Jack Replacement

I know this is obvious, but backup your iPad with iTunes before you start. I'd also turn off your passcode if you have one.

Ther first time you heat up the iOpener for this repair when its room temperature I had to heat it up for more than 30 seconds. I remember I had to heat it up for around 45 seconds. However, after that when you need to reheat it again during the repair 30 seconds will be enough.

I used the wheat bag in a sensor microwave heating up to 65-70 deg C (155 def F).

Get yourself a cherry pit bean bag the size of your iPad. Heat it, put the iPad on it for 3 to 5 minutes or so, reheat the cherry pit bean bag, again put your iPad on it. Then heat the iOpener and start working. The cherry pit bean bag will have to be reheated several times, but it will soften the adhesive so you have less problems with the iOpener

The heating can be done very effectively (and quickly) with 3d printer heated bed. Make sure the bed is clean. Set the temperature to 60c, (130f ) and put the ipad face down for +/- 10 minutes. Repeat as needed throughout the “gentle prying” stages.

The iOpener did not work at all for me.

I had to use a heat gun and bring the edges of the case up to ~200 degrees (used an infrared thermometer to measure) before the glue would weaken. This obviously superheated the metal frame, so I also had to wear gloves to handle the phone while prying the back off with the included picks.

Repair instructions worked like a charm. Had to be patient with the iOpener and getting the screen off. I tried repeatedly without success until shifting the suction cup a bit to the left side where perhaps the glue had loosened up a bit more.

The iOpener, in my opinion, is of no help. Many warnings to say “don’t warm it too much”, but the glue doesn’t melt if not warm enough. As a result, a complete waste of time and energy. In addition, too much liquid in it, so it doesn’t lay on the device on a sufficient surface. I took a hairdryer and it worked much much better.

I used an immersion bath to heat this to 180F and applied it to the device until the outside temperature of the opener read 150F with an IR thermometer. Removing the screen took very little force with this method.

My experience. I was replacing the screen which had been cracked and a little shattered in some places. The iopener is pretty much useless, so was the suction cup. The suction cup would probably be more useful if I was doing something besides the screen. Also you probably want the clean the screen before using it so it can get good suction. I used a hair dryer on high for a couple of minutes at a time (someone on this tread suggested that). I used my exacto knife and a razor blade to get into the adhesive. First the exacto to get the initial cut, then the razor blade to go a little deeper. Could have probably just used the razor blade, but the exacto has a little more finesse. I got the razor blade in and a little under the glass then I used the picks to wedge in. I didn’t want to risk anything using the razor blade too much. Used tape to keep the shattered glass together.

My experience pt2

Fortunately the shattering was mostly on the edges and most of it had adhesive on the back so it stuck together. Just take your time and work your way around following the guide to get the screen off. Have some goof off or goo be gone to clean the frame when putting the new glass on or putting the existing one back. (someone suggested that also, very good idea). Be careful of the LCD (you should know that). The cable on my LCD was pretty tight, so I propped it up while taking the cable cover off and when I put it back on I did the same thing. I just put a bottle on the battery and leaned the back of the LCD on that while attaching the cables and putting the screws back on the cover. Also be careful with the home button and the bracket on the back of it. I had enough old adhesive on left on the bracket that it stuck back to the new glass fine. So far only 12 hours in, so we will see how that holds up when the kids get at it.

Another alternative if you do not have the iopener is to use a bed time hotwater bottle. Do not over fill it though. Just put enough hot water in to support the phone while you work around the adhesive.

I use both the hot water bottle and iopener together on Samsung's. It makes life easier

I followed the directions and heated my iOpener for 30 seconds in a 1000 watt microwave, and it came out at 160 degrees F, as verified by a infrared thermometer. This allowed me to separate the last bit of the back of my Samsung S8, which was already coming off due to a swollen battery (hence the reason for the repair).

Hallo,habe den Akku erfolgreich getauscht.Doch seitdem gibt es bei Telefonaten eine Rückkopplung für den anrufenden.Bei mir ist alles normal.Woran liegt das?Mfg

If you follow these instructions, you will crack your screen like I did. Heating the iOpener for 30 seconds, using it to melt glue, then waiting 10 minutes to reheat is useless. The iOpener can be used to maybe warm the glue on whatever side you aren’t working on. You need a hairdryer and/or a heat gun to melt the glue and separate the glass from the iPad.

Anyone want to buy an old iPad with broken glass and a dead battery?

Not everybody has a microwave. You should provide a target temperature for the iOpener and instructions for a conventional oven, or pot of warm water, or whatever. Although I will probably use a heat gun …

Three times heating opener and no luck. Tried pressing down gently on opener with a towel, and the opener broke. Wondering if I now replace table mats, fancy table cloth, etc. or will this stuff wash out.

Not impressed so far. Maybe the hair dryer next.

#### WARNUNG WENN MINIMALSTER SPRUNG IM DISPLAY IST FUNKTIONERT DAS NICHT!!! ######

Hatte einen winzigen, minimalen Sprung im Display. Ich dachte es könnte gehen, weil der Sprung “abgeschlossen” war. Er hat in einer Ecke ein winzige Glasteil rausgeschnitten. NEIN! Geht nicht. Habe alles mit viel Geduld dem iOpener und einem Föhn erhitzt. Es ist trotzdem sofort über das komplette Display zersprungen…

I’ve started with iOpener but changed very quickly to a heatgun. That was more efficient.

I could not get the iOpener hot enough to melt the glue on my ipad 6. I heated for 45 seconds once and it was boiling and it still never worked. Thank goodness contributors mentioned using a hair dryer. Using an 1700w hair dryer on high did the trick to get the screen off. Still took some time and the case got pretty hot but be patient. It took twice as long and a lot more patience to get the battery out.

I have an Ipad with touch screen issue, if i replace this part it should be Ok?

WARNING - DO NOT MICROWAVE ON A METAL MICROWAVE RACK

The metal microwave rack can heat up and melt through the iOpener cover letting the contents leak out.

Not a big issue for me as I have a heat gun and used that instead.

I opened my iPad with the iOpener. Be patient! It may take quite a bit longer to it the iOpener in the microwave than it says in the guide. My microwave can only do 800W and I had to put the iOpener in several times (maybe a total of 90-120 seconds). I recommend that you have the transparent side up an watch the bag carefully. As long a the bag doesn't bloat up and the liquid doesn't start bubbling you should be fine. But I recommend to take the iO out from time to time to check it. (More comments in Step 6.)

I gave upon the I opener and used a hairdryer. (Fixed an iPad 6)

iPad mini gen5. I used the iOpener. My microwave is 1200w with carousel. 30 sec got the iOpener to 155ºF. For the 2nd heating, after 10 minutes sitting, the temp was still around 125º so I only cooked it for 15 sec. Not enough increase so +5 sec more which me to 165-170ºF. This should be considered ballpark info because who knows the real output of the various microwaves and the quality of the IR tool used to determine temp.

To successfully open my iPad mini I applied the iOpener twice to the left edge and twice to bottom. & once to R edge. Using the suction cup was difficult for me (I'm in my 70's so my hands don't work too well anymore). I had trouble holding the guitar pick and slipping them in (at an downward angle). In the end, sliding my thumbnail along the edge opened it very slightly and allowed the pick to get into the gap. I marked the ends of all my picks with a sharpie pen for the recommended 2mm insertion to avoid going in too deep. To get the screen open it took me approx 1 hour.

I used a hot water bottle, works well as it covers the whole screen and stays hot for longer.

I ended up using a hair dryer. That iOpener thing took forever.

30 seconds sure isn’t cutting it… 45 didn’t get the screen of my iPad air 2 to budge either… even after resting on the ipad for 4 minutes.

60 seconds in the microwave, the iOpener burst.

I’ll get a new one and try once more with heating it 45 seconds and repeat that for 30 minutes like others have said here. If that doesn’t work it’ll have to be the heat gun.

K

Trust the directions! I forgot and left it in the Microwave too long and after 1 minute I had Mt Vesuvius - the iOpener burst and spewed the goodies out. The problem is, the Digitizer can be damaged by a hot air gun, so I had to tough out and remove the glue the hard way. I made it … with lots of patience! Tough lesson.

I also used a hairdryer. I used it on the low setting and I cut a piece of carboard to protect the rest of the screen. The iFixit tool and method is vert tedious and very time consuming in comparison. With the hairdryer method you can literally have the display apart in a few minutes. Using your other hand nearby the area you are heating it should be very hot but not enough to burn your hand. You only have to heat metal part of case near glass edge. If you have a cellular model then you need to be very careful because the black antenna area is plastic. So less heat and work your way up in adding heat just enough to separate around the area but not so much you melt the plastic!

iOpener was the worst part of the kit. Followed directions for :30 in microwave and took 4 trips to the microwave to loosen adhesive on left side of home button. I thought I was figuring it out and it was working well… even set a timer to wait 10 minutes between heating it up. Was on the right side and was on my 12th heat up when it exploded in the microwave. My only tip is that if you set it clear side up, as soon as you see any bubbles or boiling in the liquid, STOP! If you put a pot holder over the iOpener and press slightly to make good surface contact, that seemed to help. I finished heating with a “Corn Sack” that held heat better than the provided iOpener.

Get a heat gun.

I followed the directions and heated my iOpener for 30 seconds in a 1000 watt microwave, and it came out at 160 degrees F, as verified by a infrared thermometer. A second heating about 15 minutes later in the micro and it came out at 190 degrees F. Plenty hot enough to soften the adhesive for removing the back on my S8. Based on the comments above I think people just need to use more patience.

I used various time settings. It got very hot. It would soften the glue but not a whole lot. If my screen had been intact and I was replacing something that was not a digitizer, it may have worked. A broken screen makes the process significantly more difficult. I ended up breaking the home button cable. Good bye TouchID…

After reading previous comments I didn't even use the i-opener. Used the heatgun ( hairdryer ) which works great for me. Maybe I was lucky as this is my first attempt at replacing a cellphone battery. Motoz 3

It appeared 30 seconds were not enough, so I heated it more, by 5 seconds at a time until I got the right temperature about 70 degrees Celsius (measured with infrared pistol) to get the screen heated up to 60 C, the best for softening the glue. But the heat was quickly dissipating by the big aluminum back cover, so the best I got in 2 minutes of applying iOpener was around 45 C, which made the procedure difficult and having risk of breaking the screen. So I eventually abandoned iOpener and user a hot air gun with precise temperature setup. I set it to 90 C, which allowed me to open my iPad quickly and safely.

I, too, ended up using a hot air gun. I’ve done earlier versions of iPad before but the adhesive used on this IPad 5 A1822 was particularly difficult to remove.

Also, while the suction cup worked great when the glass is in tact, any cracks in the glass make the suction cup useless.

You need to remember here are different sizes of microwaves. I had the same issue.

Heating on a smaller unit I used 45-60 seconds. That worked but was time comsuming

I vote for the hair dryer. The other methods work too but if you aren’t having any luck, switch to the hair dryer. While holding the iPad in my hand, I found that I am aiming the dryer at my finger at the same time and it gauges how hot it is. I stop when my finger can’t take it - maybe five seconds up close. Repeat as needed like I did.

This thing melts when placed up side down in the microwave…

If the maximum temperature for this iOpener is lower than the gadget glue minimum temperature, this device does not make sense.
I think the maximum temperature for this iOpener is below 100⁰C and most gadget glue minimum temperature is higher than 100⁰C. So the iOpener is useless for many opening steps in repair guides. But who knows because temperature range is not specified for this iOpener.

When boiling in water you can put the iopener in a ziplock to keep it dry.

Echo jesseokerlund's comments that you will have glass flying. I made the mistake of doing the repair at my kitchen table and had a lot of cleanup to do. The job would be much easier if there was no broken glass, and the hardest part is where the glass is broken right next to the bezel. I used the metal spudger to work those pieces free, but it takes some time.

+ 1 on the safety glass, I almost got hurt while doing this.

I followed all the safety precautions mentioned: tape, safety glasses… The best advice I saw on this is to put the iPad in the sun for a few minutes. I placed mine on the windshield of my car in direct sunlight for about 5 minutes. I also used the iOpener to keep heat on the edges I wasn’t working on. I was able to easily remove the glass without any shards flying in about 30-40 minutes total. Great advice and safest way I’ve seen to remove broken glass.

Badly broken screen, taped and warmed about 15 minutes on heating pad set on high. Perfect, gentle, overall warming! Mark the front with Sharpie, ie WiFi, cable, etc. Used thin metal iSes... type tool and guitar pics. BUY NEW Plastic bezel!!! So super cheap. Rewarm on heating pad as necessary. Compressed air helpful to blow away tiny glass bits. Wear glasses! Take breaks! This is easy if you warm carefully and are patient!

I am in the process of replacing a shattered screen on an iPad 3 wifi, and I literally was removing glass piece by piece! I do recommend having a roll of wide clear sealing tape at hand. Then, when you see loose glass shards, pull off about 4 to 5 inches, and stick the tape to pick up the loose glass, and once in a while, fold the tape onto itself (sticky to sticky side), and set it aside. This helps keep it from getting everywhere. Also, spread news paper under your work. Some people don't really think of these things, but the fact is, hardened glass will find its way into your skin very easily. Extremely sharp!

Have not attempted this repair on my wife's iPad 2, but is there a reason that you put the iOpener on top of the device rather than putting the device on top of the iOpener? After all, heat rises.

There is a way of making the Wifi/Bluetooth Antenna replacement much easier. If you have a steady hand and a soldering iron simply desolder the connecting cable from the bottom of the antenna and solder it back onto the new antenna. This means there is no need to dismantle the iPad and the repair is much faster. Hope this helps :-)

Had much more success using the metal spudger versus the plastic opening tool that came with the front panel kit.

Pay attention to the Power Button cable located in the upper right corner !!!

Successful battery change but I did sever the cord/ribbon to the power/sleep button. As my iPad had been opened before at a repair shop, I think they put adhesive over the cord as the small section was stuck underneath the LCD, barely visible. So be careful not to put adhesive above that exposed ribbon/cord to the power/sleep button or the next time you open it up, it's severed.

On the iPad 2 I repaired, the opening started at 1 inch and ended at 3mm.

Like others i found the plastic tool pretty useless. Exacto, razor blade, or small metal pick/pry tool works much better to get that first guitar pick inserted. Be careful not to damage the bezel too much. Unless to plan to replace it.

If you have an iPAD that has been repaired before note that the adhesive strip might not have an opening by the volume control as shown. I replaced the glass and the new glass had a 2" gap to the left of the Home button only.

The glass is much thinner than you'd think and I broke mine trying to lever it off before the adhesive has softened enough. Be VERY gentle!

My plastic opening tool broke in no time flat. Perhaps I was pressing down too hard and not wiggling it enough. But for me I found that the metal spudger was the best tool for the job. I was able to wiggle it while slowly prying up the glass and once it was under the surface of the glass I was able to work it along the edge quite easily. I saw that some people used a razor blade but I would be afraid the blade would break. The metal spudger was just thin enough to do the job well.

!!!!!!razor-blade & hair-dryer !!!!!!!

I have found that using these plastic picks, spudgers and edge tools are ineffective as tools for inserting or creating a gap and glue separation action.

They are just too soft and too thick for this, causing cracks and not able to reach underneath without causing stresses.

After heating the adhesive with a heat gun (and using cardboard to shield the lcd screen) I have been using a metal round headed scalpel to insert between the glass and bezel, and to very carefully use as an adhesive separation tool at a very oblique angle so as to miss any sensitive cables or components.

Also, instead of this iTool heating pad and a microwave, they should create an electrically heated shaped pad, this would avoid the constant cooling and reheating and maintain the right temperature.

Addendum, I have a temperature controlled heat gun, and set it to 180F for this.

Yoh but this is not so simple of your screen is shattered to the edges. Basically I had to lift, shatter more, and then pick off the splintered glass with tweezers bit by bit. Patience is a virtue here. I gave up on saving the adhesive and used it to help remove the splinters. I basically removed the edges of the iPad like that and then lift glass off. WEAR SAFETY GLASSES. I would be blind now if I didn’t. wifi antenna -Go slow make sure it’s hot +check what you are doing in the crack. Remove all splinters fromiPad when it’s open. Clean LCD with a microfibre cloth and inside of your new digitizer. When I first reassembled, the home button didn’t work. I reopened and made sure the two gold connectors align with the two spikes on the body. I placed the home button board face down onto the connector spikes with adhesive on the other side, then lowered the digitiser onto it so the board would stick to the digitiser. Notes: forget plastic spudger they’re only place holders, I used a blade knife and metal Spudgers

Irreversible damage to the Wi-Fi antenna is nearly unavoidable, but this is not the end of the world since you can pick up a perfectly fine replacement on-line for a few bucks. Many digitizer screen replacement kits include a new WiFi antenna and new bezel since removing the screen without damage to these is also nearly impossible. If your iPad is old enough to need a new battery, and you plan on keeping it thru at least another battery's expected life span, then I would plan on replacing the digitizer screen, bezel, and WiFi antenna as part of the battery replacement. The battery is going to be the most expensive of the set, say around $15 (US), and adding the other three will only add about another $15 (check the prices in ebay, amazon, etc.). Removing the screen often results in damage to the on/off and volume control cable since it too runs along the upper right hand edge of the base right under the screen. If you cut thru this then add another $1 to replace it too.

Based on my experience just (nearly) completing this job on an iPad 2, CDMA, is that the trickiest step is reconnecting the three CDMA antenna cables on the underside of the CDMA chip that is part of the logic board assembly. These are nearly microscopic button connectors (maybe 0.5 mm in diameter). I needed 8X magnification glasses, very bright light, tweezers, and incredible luck to get these reattached. They pop off no problem, but getting them positioned to apply pop-on force takes a LOT of patients! Maybe someone knows a trick to doing this? There’s a similar connector on the WiFi cable but the chip it attaches to can be removed from the logic board so you’re able to manage positioning them interdependently. The CDMA chip is attached (soldered?) to the logic board and the three button connectors are on the underside, and pretty close to one another, so getting all THREE attached and then the logic board in place is a miracle.

This BEGS for an Archer "Just The Tip" reference.

It wasn't obvious to me at first that I'd broken the antenna. A picture of the antenna that works compared with one that is broken would be useful. Fortunately I'd ordered the replacement part just in case, as suggested.

I think using extra heat on this spot may make it easier to unstick without breaking the antenna?

A diagram of what the antenna looks like, from the side, would make it clearer what to do with the pick. You are trying to detach the antenna from the glass, without ripping it off where it's screwed into the bottom of the ipad. Since you can't see what you are doing, and the antenna is quite fragile, that's tricky.

I think once you've broken one you would know better how to do it. When you slide the pick to the right you need to be sure the pick is moving above the antenna and not snagging on it in any way, and you need to be sure the antenna is completely detached from the glass, so you don't tear it when you lift the glass up.

Can anybody give me a clue as to what the exact part is in step 57, As there are slightly different cables for the ipad 2, Mine is A1395, Thanks.

Another lesson learned while removing the WiFi antenna. The photo shows the iPad laying face up on the table, but to see what you’re doing when detaching the antenna you ‘re better off with the iPad edge up so you can see how the antenna is attached. The antenna is very, very easily broken. To be honest, it’s a lot easier to replace a broken antenna than to try to pry it loose.

Please mind that the GSM model has on the upper side left and right from the front camera the 3G antennas. When I removed the broken glass I cut the right one off which I have to fix now.

The GSM component is glued to the screen with different adhesive (more like glue). I managed to not damage this but it was really tricky. The guitar pick is too thick and weak to release this from the screen. Id recommend you wait until you lift the glass (future step, NOT NOW). Then, with a good light you'll see the white plastic adhered to the glass. A thin metal pick or exacto is needed to patiently cut & pry your way through the adhesive. Careful of the camera as your pulling in that direction.

There is an error in the red text in this step. It says ‘The digitizer cable is located approximately 2" from the bottom of the iPad’. The next sentence says .. ‘Stop sliding the pick when you get ~2.25" from the bottom of the iPad.. This will slice and ruin that cable. The last sentence should read ‘Stop sliding the pick when you get ~1.75" from the bottom of the iPad.’ so you stop cutting glue before you get to the digitizer cable.

@Jenny & @dleimonis - you can buy the digitizer and new cable by itself if you do not need an LCD also. They are separate parts.

At this point it is a good idea to get the packing tape back out and wrap it around 2 or 3 of your fingers making a circle with the sticky on the outside. Make it loose enough you can place your fingers on the table surface to the side and pull your fingers out. When you remove all the tiny parts/screws in the next steps put them on top of the tape so you know exactly where they are when you need them

you can use latex gloves to keep smudges and finger prints from the screen. I'm getting ready to repair mine, thanks for all the comments and tips. Btw, I wonder if a vacuum cleaner would work for removing small pieces of glass.

De Dios sept.10 2014

where is the connecotr for home button at the ipad 3....i have nothin where i can plug in the flex cable comin from the button

Go slowly as you lift up the glass and be sure that you are not tearing a ribbon cable. When I lifted the glass the digitizer cable was torn and unusable. Perhaps I had cut it with the pick/spudger but it tore completely off when I lifted the glass. Good thing I had purchased the full front panel assembly with the digitizer (IF116-018-3).

When reassembling I used canned air to blow off dust on the LCD before closing it up.

You can use a clean soft brush like a make-up brush or small paint brush to brush off the LCD.

I like how the pictures show an intact screen being removed (although the one in step 4 has a couple of cracks in). I don’t know if anyone would have the luxury of being able to remove a screen in one piece, the ipads I've fixed have been completely smashed pretty much all the way around the outside of the lcd underneath. I used this guide to know where to watch for cables etc - very helpful. I end up using a window scraper/razor to scrape off the glass shards/adhesive around the edge. Glass shards/dust all over the lcd is easy enough to get off but cleaning the lcd after that is a real pain. Does anyone have any suggestions how to clean the lcd properly?

When reassembling the glass, align the camera first. On the back of the glass there are two pins on the metal camera frame.

Align them to the camera first, in order to avoid to get a ‘bulge’ visible on the glass or on the back of the iPad.

+1 to Luca’s comment. This deserves a RED NOTE for reassembly. I probably just destroyed my new wifi antenna due to not having a reassembly call out for alignment of the screen. Had to pry things back apart and wifi antenna looks like it may have bit the dust. So this is a VERY important bit to know for a first timer.

When reinstalling the front panel check the home button’s ribbon cable doesn’t get trapped. If it gets folded back on itself, the cable will break and you’ll have a reassembled iPad with a non-functioning home button.

use the same way in reverse mode!!
