Background and Identification

The ASUS FonePad is a series of 6-, 7-, and 8-inch phablets (a class of mobile devices straddling the size format of smartphones and tablets). The ASUS FonePad series is officially a line of tablet computers, but because they include mobile cellular telephone capabilities, they are marketed as phablets by ASUS. The FonePad 7 was released in two different models, the ASUS Fonepad 7 LTE ME372CL with LTE band and the ASUS Fonepad 7 ME175CG with 3G and Intel Atom Z2520 1.2 GHz processor. The models were available in black and white body colors.

The ASUS FonePad 7 features a 7-inch display with a resolution of 800 pixels by 1280 pixels. The FonePad 7 includes 1 GB of RAM and either 8 GB, 16 GB, or 32 GB of internal storage. The phablet includes a 5-megapixel main camera and a 1.2-megapixel selfie or front-facing camera. The device includes a 3.5 mm headphone jack. The FonePad 7 includes a 3850 mAh non-removable battery, meaning that the battery’s adhesive is permanent, making repair and replacement difficult, but not necessarily impossible.

The ASUS FonePad 7 includes relatively thick front bezels with the front-facing camera located in the center of the device’s top bezel. The name “ASUS” is included in the center of the phablet’s backing, and the main camera is located directly above the ASUS logo. The Intel logo is also included on the phablet’s backing, which includes the name “Intel” in lowercase letters inside of an oval.

Technical Specifications

Models:

  • Asus Fonepad 7 LTE ME372CL with LTE band
  • Asus Fonepad 7 ME175CG with 3G and Intel Atom Z2520 1.2 GHz processor

Release date: October 2013

Body:

  • Dimensions and Weight: 196.8 x 120 x 10.5 mm (7.75 x 4.72 x 0.41 in), 328 g (11.57 oz)
  • SIM: Micro-SIM

Display:

  • Type: IPS LCD capacitive touchscreen, 16M colors
  • Size: 7.0 inches, 142.1 cm2 (~60.2% screen-to-body ratio)
  • Resolution: 800 x 1280 pixels, 16:10 ratio (~216 ppi density)

Platform:

  • OS: Android 4.2 (Jelly Bean), upgradable to 4.4.2 (KitKat)
  • Chipset: Intel Atom Z2560
  • CPU: Dual-core 1.6 GHz
  • GPU: PowerVR SGX544MP2

Memory:

  • Card slot: microSDHC (dedicated slot)
  • Internal: 8GB 1GB RAM, 16GB 1GB RAM, 32GB 1GB RAM

Main Camera:

  • Single: 5 MP, AF
  • Video: 1080p@30fps

Selfie Camera:

  • Single: 1.2 MP
  • Video: 720p

Sound:

  • Loudspeaker: Yes
  • 3.5 mm jack: Yes

Communications:

  • WLAN: Wi-Fi 802.11 a/b/g/n, dual-band
  • Bluetooth: 3.0
  • GPS: Yes, with A-GPS, GLONASS
  • Radio: No
  • USB: MicroUSB 2.0, USB On-The-Go

Features:

  • Sensors: Accelerometer, proximity, compass

Battery:

  • Li-Po 3950 mAh, non-removable (15 Wh)
  • Stand-by: Up to 840 h (3G)
  • Talk Time: Up to 10 h (multimedia) (2G) / Up to 28 h (3G)

Miscellaneous:

  • Colors: Sapphire black, Diamond white
