Background and Identification

The Acer Aspire 5536 15.6" is a PC laptop by Acer, released in 2009. Acer is a Taiwanese hardware and electronics corporation that concentrates on advanced electronics technology. Their products include PCs, laptops, tablets, storage devices, and much more. The Acer Aspire line is aimed at casual household users and covers both desktop and laptop PCs.

The Acer Aspire 5536 is sold with one of several AMD processors. It runs on the Windows Vista Home Basic or Premium operating system. The system is sold with up to 4 GB of DDR2 RAM memory that can be upgraded to 8 GB using two SODIMM slots. Lower-end models are sold with 2 GB of RAM that can be upgraded to 4 GB. Acer Aspire 5536 models are sold with either 160, 250, 320, or 500 GB of hard-disk drive storage.

The Acer Aspire 5536 has a matte black body with a touchpad off-center to the left side of the computer’s base. The Acer logo is located directly under the display, as well as behind the display. The display is 15.6 inches with 1366 by 768 pixels. The laptop requires the base unit to be completely disassembled to be upgraded or repaired, and the battery requires quite a bit of effort to remove.

Technical Specifications

Operating system:

  • Genuine Windows Vista® Home Premium 64-bit2 (Service Pack 1)
  • Genuine Windows Vista® Home Premium (Service Pack 1)
  • Genuine Windows Vista® Home Basic 64-bit2 (Service Pack 1)
  • Genuine Windows Vista® Home Basic (Service Pack 1)

Platform: AMD Better By Design program, featuring:

  • AMD Turion™ X2 Ultra dual-core mobile processor ZM-82/ ZM-84/ ZM-85/ ZM-86/ ZM-87 (2 MB L2 cache, 2.20/2.30/2.30/2.40/2.40 GHz, DDR2 800 MHz, 35 W), supporting AMD HyperTransport™ 3.0 technology
  • AMD Turion™ X2 dual-core processor RM-72/RM-74/RM-75 (1 MB L2 cache, 2.10/2.20/2.20 GHz, DDR2 800 MHz, 35 W), supporting AMD HyperTransport™ 3.0 technology
  • AMD Athlon™ 64 X2 dual-core processor QL-62/QL-64/QL-65 (1 MB L2 cache, 2/2.10/2.10 GHz, DDR2 667 MHz, 35 W), supporting AMD HyperTransport™ 3.0 technology
  • AMD M780G Chipset
  • Acer InviLink™ Nplify™3, 4, 802.11b/g/Draft-N Wi-Fi CERTIFIED® network connection, supporting Acer SignalUp™ wireless technology

* Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED® network connection, supporting Acer SignalUp™ wireless technology

System memory:

  • Dual-channel DDR2 SDRAM support
  • Up to 4 GB of DDR2 667 MHz memory, upgradeable to 8 GB using two soDIMM modules for (for 64-bit OS)
  • Up to 2 GB of DDR2 667 MHz memory, upgradeable to 4 GB using two soDIMM modules (for 32-bit OS)7

Display:

  • 15.6" HD 1366 x 768 pixel resolution, high-brightness (220-nit) Acer CineCrystal™ TFT LCD, supporting simultaneous multi-window viewing via Acer GridVista™
  • 16:9 aspect ratio
  • 8 ms high-def response time
  • 60% color gamut

Graphics:

* ATI Radeon™ HD 3200 Graphics with up to 20488 MB of HyperMemory™ (256 MB of dedicated system memory, up to 1792 MB of shared system memory), supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 4.0, Microsoft® DirectX® 10.0

  • Dual independent display support
  • 16.7 million colors

* MPEG-2/DVD decoding

  • WMV9 (VC-1) and H.264 (AVC) decoding
  • HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
  • Acer Arcade™ Deluxe featuring Acer CinemaVision™ and Acer ClearVision™ technologies

Audio:

  • Dolby®-optimized surround sound system with two built-in stereo speakers
  • Optimized 3rd Generation Dolby Home Theater®10 audio enhancement, featuring Dolby® Digital Live, Dolby® Pro Logic® IIx, Dolby® Headphone, Dolby® Natural Bass, Dolby® Sound Space Expander, Dolby® Audio Optimization, Dolby® High-Frequency Enhancer technologies
  • True5.1-channel surround sound output
  • High-definition audio support
  • S/PDIF (Sony/Philips Digital Interface)12 support for digital speakers
  • MS-Sound compatible
  • Built-in microphone

Storage:

  • 160/250/320/500 GB or larger hard disk drive
  • Multi-in-1 card reader, supporting Secure Digital™ (SD) Card, MultiMediaCard (MMC), Memory Stick™ (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)

Optical media drive:

  • 8X DVD-Super Multi double-layer drive:
  • Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 6X DVD-ROM DL (double-layer), 6X DVD-R DL (double-layer), 6X DVD+R DL (double-layer), 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM
  • Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 4X DVD-R DL (double-layer), 4X DVD+R DL (double-layer), 6X DVD-RW, 8X DVD+RW, 5X DVD-RAM

Dimensions and weight:

  • 383 (W) x 250 (D) x 26/37 (H) mm (15.1 x 9.9 x 1.03/1.5 inches)
  • 2.8 kg (6.16 lbs.) with 6-cell battery pack

Power:

  • ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
  • 48.8 W 4400 mAh 6-cell Li-ion battery pack:
    • 3-hour battery life
  • 2.5-hour rapid charge system-off, 3.5-hour charge-in-use
  • 3-pin 65 W AC adapter
  • ENERGY STAR® 5.0

I/O ports:

* Multi-in-1 card reader (SD™ , MMC, MS, MS PRO, xD)

  • Four USB 2.0 ports
  • Acer Bio-Protection fingerprint reader
  • HDMI™ port with HDCP support
  • External display (VGA) port
  • Headphone/speaker/line-out jack with S/PDIF support
  • Microphone-in jack
  • Line-in jack
  • Ethernet (RJ-45) port
  • Modem (RJ-11) port
  • DC-in jack for AC adapter
