Troubleshooting

The troubleshooting page for the device can be seen here

Asus Chromebook C213SA-YS02 Troubleshooting

Background and Identification

The Asus Chromebook C213SA-YS02 was released in June of 2017, which was marketed as a lower budget laptop. To check if your computer is the right model, look on the back of the computer on the center sticker for the model number. The 11.6 inch display touchscreen is portable and compact and is held by dual zinc-alloy hinges that allow the laptop to be in stand, tent, or tablet mode. The chassis is built with an anti-scratch and anti-fingerprint rubber coated material that is designed to meet MIL-STD 810G military specifications. The actual internal workings of the Asus C213SA-YS02 include a 1.1GHz Intel Apollo Lake dual-core Celeron N3350 CPU, integrated graphics, and 4GB of RAM. There are two cameras on the C213SA, one on top of the display and one near the top of the keyboard. The display camera has a resolution of 1 megapixel while the keyboard camera has a resolution of 5 megapixels.

Specifications

  • Processor: Intel® Celeron® Dual-Core N3350 Processor, 1 GHz (2 M Cache, up to 2.4 GHz
  • Operating System: Chrome OS
  • Chipset: Integrated Intel® CPU
  • Memory: 4 GB Onboard Memory
  • Display: 11.6" (16:9) LED backlit HD+ (1366x768) 60Hz Anti-Glare Touchscreen with 50% NTSC with 178˚ wide-viewing angle display
    11.6" (16:9) LED backlit HD+ (1366x768) 60Hz Glare Touchscreen with 45% NTSC with 178˚ wide-viewing angle display
  • Graphic: Integrated Intel HD Graphics
  • Storage: eMMC ''32GB
  • Keyboard: Chicklet keyboard
  • Card reader: Multi-format card reader (SD/SDHC/SDXC)
  • WebCam: Front 1 MP and Rear 5 MP *1
    HD camera (Front)
  • Wifi: Integrated 802.11a/b/g/n/ac(2x2)
  • Bluetooth: Built-in Bluetooth V4.0
  • Interface: 1 x COMBO audio jack
    2 x Type A USB3.0 (USB3.1 GEN1)
    2 x Type C USB3.0 (USB3.1 GEN1) support display & support power delivery
    1 x micro SDXC card reader
    1 x Volume up/down
  • Audio: Built-in Stereo 2 W Speakers And Dual-Array Microphone
  • Battery: 4 Cells 46 Whrs Polymer Battery
  • Power Adapter:Plug Type :USB TYPE C
    Output :
    15 V DC, 3 A, 45 W
    Input :
    100 - 240 50/60 Hz universal (while attached)
  • Dimensions: 307 x 199 x 20.65 cm (WxDxH)
    307 x 199 x 20.9 cm (WxDxH)
    *2
  • Weight: 1.25 lbs with Battery
  • Security: Kensington lock
  • Certificates: UL, CE Marking Compliance, FCC Compliance, BSMI, Australia C-TICK / NZ A-Tick Compliance, CB, EPEAT, EU Flower, Energy star, IDA, WEEE, Erp 2013, RoHS, JATE
  • Manufacturer Warranty: 1-year International warranty. *different by country
    1-year battery pack warrant
  • Note: *1: use for Tablet Mode
    *2: with Stylus supported model

specifications were found from this source: Asus Chromebook C213SA-YS02 Specifications


Additional Information

Here are some helpful links regarding the Asus Chromebook C213SA-YS02
