DJI Phantom 4 Repair

Phantom is a series of UAVs (or unmanned aerial vehicles) designed and manufactured by DJI, a Chinese technology company. The Phantom 4 is the fourth generation of the Phantom UAV series and was released in March 2016. Phantom 4 production ended in April 2017 with the launch of the Phantom 4 Advanced model.

The Phantom 4 has an improved quick-release propeller system when compared with its predecessors. This model also features obstacle avoidance and subject tracking, as well as GPS, a camera gimbal, sonar, five safety sensors, and a gyroscope. The Phantom 4 has a larger battery than the Phantom 3, so it is slightly larger and heavier. In ‘Sport Mode,’ The Phantom 4 has a maximum speed of 20 meters per second or 45 miles per hour. It has a maximum flight range of 5 kilometers. The Phantom 4 has the same maximum video transmission technology as the Phantom 3 Pro and Advanced.

The Phantom 4 Pro has upgraded obstacle avoidance and includes two different remote controllers. The Phantom 4 Advanced model was designed to replace the original Phantom 4 and uses the same camera sensor as the Phantom 4 Pro.

The Phantom 4 can be identified by its white quadcopter body and the name “Phantom” in all capital letters above the camera gimbal.

Aircraft:

• Takeoff Weight (battery and propellers included): 1380 g
• Diagonal Size: 350 mm
• Max Ascent Speed: S-mode: 6 m/s
• Max Descent Speed: S-mode: 4 m/s
• Max Speed (near sea level, no wind): S-mode: 20 m/s
• Max Flight Time (no wind): 28 minutes
• Max Wind Speed Resistance: 10 m/s
• Max Service Ceiling Above Sea Level: 19685 feet (6000 m)
• Max Tilt Angle:
  • S-mode: 42°
  • A-mode: 35°
  • P-mode: 15°
• Max Angular Velocity:
  • S-mode: 200°/s
  • A-mode: 150°/s
• Operating Temperature Range: 32° to 104°F (0° to 40°C)
• Satellite Positioning Systems: GPS+GLONASS
• Hovering Accuracy Range:
  • Vertical:
    • ± 0.1 m (when vision positioning is active)
    • ± 0.5 m (with GPS positioning)
  • Horizontal:
    • ± 0.3 m (when vision positioning is active)
    • ± 1.5 m (with GPS positioning)
• Internal Storage: 8 GB

Vision System:

• Vision System:
  • Forward Vision System
  • Downward Vision System
• Vision Range: ≤10 m/s (2 m above ground)
• Altitude Range: 0 - 33 feet (0 - 10 m)
• Operating Range: 0 - 33 feet (0 - 10 m)
• Obstacle Sensory Range: 2 - 49 feet (0.7 - 15 m)
• FOV:
  • Forward: 60°(Horizontal), ±27°(Vertical)
  • Downward: 70°(Front and Rear), 50°(Left and Right)
• Measuring Frequency:
  • Forward: 10 Hz
  • Downward: 20 Hz
• Operating Environment: Surface with clear pattern and adequate lighting (lux>15)

Remote Controller:

• Operating Frequency: 2.400 - 2.483 GHz
• Max Transmission Distance:
  • FCC Compliant: 3.1 mi (5 km)
  • CE Compliant: 2.2 mi (3.5 km)
• Operating Temperature Range: 32° to 104°F (0° to 40°C)
• Transmission Power (EIRP):
  • FCC: 23 dBm
  • CE: 17 dBm
  • MIC: 17 dBm
• Battery: 6000 mAh LiPo 2S
• Operating Current/Voltage: 1.2 A@7.4 V
• Mobile Device Holder: Tablets and smartphones

Intelligent Flight Battery

• Capacity: 5350 mAh
• Voltage: 15.2 V
• Battery Type: LiPo 4S
• Energy: 81.3 Wh
• Net Weight: 462 g
• Charging Temperature Range: 41° to 104°F (5° to 40°C)
• Max Charging Power: 100 W

Gimbal:

• Controllable Range: Pitch: -90° to +30°
• Stabilization: 3-axis (pitch, roll, yaw)
• Max Controllable Angular Speed: Pitch: 90°/s
• Angular Vibration Range: ±0.02°

Camera:

• Sensor:
  • 1/2.3” CMOS
  • Effective pixels:12.4 M
• Lens: FOV 94° 20 mm (35 mm format equivalent) f/2.8 focus at ∞
• ISO Range:
  • Video: 100-3200
  • Photo: 100-1600
• Electronic Shutter Speed: 8–1/8000s
• Still Image Size: 4000×3000
• Still Photography Modes:
  • Single shot
  • Burst shooting: 3/5/7 frames
  • Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias
  • Timelapse
  • HDR
• Video Recording Modes:
  • UHD:
    • 4096×2160 (4K) 24 / 25p
    • 3840×2160 (4K) 24 / 25 / 30p
    • 2704×1520 (2.7K) 24 / 25 / 30p
  • FHD: 1920×1080 24 / 25 / 30 / 48 / 50 / 60 / 120p
  • HD: 1280×720 24 / 25 / 30 / 48 / 50 / 60p
• Max Video Bitrate: 60 Mbps
• Color Mode: Dlog-M (10bit), support HDR video (HLG 10bit)
• Supported File System:
  • FAT32 (≤ 32 GB)
  • exFAT (> 32 GB)
• Photo Format: JPEG / DNG (RAW)
• Video Format: MP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265)
• Supported SD Cards:
  • Micro SD
  • Max capacity: 64 GB
  • Class 10 or UHS-1 rating required
• Operating Temperature Range: 32° to 104°F (0° to 40°C)

Charger:

• Voltage: 17.4 V
• Rated Power: 100 W

APP/Live View

• Mobile App: DJI GO 4
• Live View Working Frequency: 2.4 GHz ISM
• Live View Quality: 720P @ 30fps
• Latency: 220ms
