Background and Identification

The Dell Precision 7520 is a mobile workstation laptop released by Dell in March 2017 as part of its Precision line of mobile workstations. Dell Precision is a series of mobile and fixed computer workstations designed for professional consumers and CAD/Architecture/CG professionals, or as small-scale business servers. The Precision series was launched in 1997.

The Dell Precision 7520 includes a 15.6-inch display with a resolution of 1920 by 1080 pixels with an optional touchscreen or an anti-glare LED 15.6-inch display with a resolution of 3840 by 2160 pixels. According to a review of the Dell Precision 7520 by Laptop Mag, the laptop’s 2.8-kilogram or 6.2-pound weight is heavy, even for a workstation. However, the review also found that the Dell Precision 7520 has a ruggedized construction, even though it is bulky for its class. The Dell Precision 7520 includes a metal chassis and a carbon-fiber lid that is tough enough to pass a variety of Military Standard 810G tests. The laptop includes three USB 3.0 ports, including PowerShare for charging devices using the laptop’s battery, an SD card slot, an audio jack, and a Kensington lock slot on the right edge. On the left edge, the laptop includes another USB 3.0 port with PowerShare, a full HDMI output, a mini DisplayPort, a SmartCard reader, and a Thunderbolt 3 port that uses a USB-C connection.

The Dell Precision 7520 includes a 3.9- by 2.2-inch touchpad that includes three mouse buttons (the right and left buttons for right and left clicking, and a center button for scrolling). It also includes a pointing stick just below the home key row and three more mouse buttons just below the spacebar.

Technical Specifications

Processor:

  • Intel 7th Generations Processors Intel Core Xeon E3-1535M v6 Quad Core Xeon 3.10GHz, 4.20GHz Turbo, 8MB 45W
  • Intel Core Xeon E3-1505M v6 Quad Core Xeon 3.00GHz, 4.00GHz Turbo, 8MB 45W Intel Core i7-7920HQ Quad Core 3.10GHz, 4.10GHz Turbo, 8MB 45W
  • Intel Core i7-7820HQ Quad Core 2.90GHz, 3.90GHz Turbo, 8MB 45W
  • Intel Core i7-7700HQ Quad Core 2.80GHz, 3.80GHz Turbo, 6MB 45W
  • Intel Core i7-7440HQ Quad Core 2.80GHz, 3.80GHz Turbo, 6MB 45W
  • Intel Core i5-7300HQ Quad Core 2.50GHz, 3.50GHz Turbo, 6MB 45W
  • Intel 6th Generation Processors:

** Intel Core Xeon E3-1575M v5 Quad Core Xeon 3.00GHz, 3.90GHz Turbo, 8MB 45W

  • Intel Core Xeon E3-1545M v5 Quad Core Xeon 2.90GHz, 3.80GHz Turbo, 8MB 45W
    • Intel Core i7-6920HQ Quad Core 2.90GHz, 3.80GHz Turbo, 8MB 45W
    • Intel Core i7-6820HQ Quad Core 2.70GHz, 3.60GHz Turbo, 8MB 45W

Operating System:

* Windows™ 7 Pro (64-bit) w/ 6th Gen Processors, Windows™ 8.1 Pro (64-bit) W/6th Gen Processors, Windows™ 10 Pro (64-bit), Windows™ 10 Home (64-bit), Canonical Ubuntu 16.04 SP1, RHEL 7.3

Chipset: Intel Mobile CM238

Memory:

  • 4 DIMM slots: up to 64GB DDR4 NECC 2400MHz
  • Up to 64GB DDR4 ECC DDR4 2400MHz
  • Up to 32GB DDR4 2667MHz SuperSpeed memory

Graphics:

  • Radeon Pro WX 4130 with 2GB GDDR5 dedicated memory
  • Radeon Pro WX 4150 with 4GB GDDR5 dedicated memory
  • NVIDIA Quadro M1200 with 4GB GDDR5 dedicated memory
  • NVIDIA Quadro M2200 with 4GB GDDR5 dedicated memory
  • Intel® HD Graphics P580, 630

Display Options:

  • 15.6” FHD TN (1920x1080) Anti-Glare LED-backlit (42% color gamut)
  • 15.6” UltraSharp™ FHD IPS (1920x1080) Wide View Anti-Glare LED-backlit with Premium Panel Guarantee (72% color gamut)
  • 15.6” UltraSharp™ FHD IPS Touch (1920x1080) Wide View LED-backlit with Premium Panel Guarantee (72% color gamut)
  • 15.6” UltraSharp™ UHD IGZO (3840x2160) PremierColor Wide View Anti-Glare LED-backlit with Premium Panel Guarantee (100% Adobe color gamut)

Storage Options:

  • Support for two storage devices: one M.2 PCIe solid state drive and one M.2 PCIe/2.5” SATA drive: Dell Fast Response Free Fall Sensor standard
  • Hard Disk Drive (HDD): 2.5” 500GB, 1TB 7200RPM up to 2TB 2.5” 5400RPM SATA 6Gb/s
  • Solid State Drive (SSD): 256GB, 512GB, 512GB SED (Check regional availability), 1TB 2.5” SATA 6Gb/s
  • M.2 PCIe NVMe Solid State Drive (M.2 SSD): 256GB, 512GB, 512GB SED (Check regional availability), 1TB SSD

Communication Options:

  • Wired: Integrated Intel I219LM 10/100/1000 Gigabit Ethernet
  • Wireless LAN & Bluetooth: Intel® 8265 Dual-Band 2x2 802.11 ac Bluetooth® 4.2, Dell DW1820 2x2 801.11ac + Bluetooth 4.2,
  • Mobile Broadband & GPS: DW5811e (Gobi 4g/LTE – FMC)

Multimedia:

  • Dual integrated high quality speakers and optional dual integrated noise cancelling digital array microphones
  • MaxxAudio® Pro by Waves
  • Optional integrated light sensitive HD video webcam

I/O Ports and Connectors:

  • 1 x SD Card Reader (SD, SDHC, SDXC, supporting up to 2TB); 1 x Thunderbolt® 3
  • 4 x USB3.0 with PowerShare; 1 x mDP 1.4; 1 x HDMI 1.4; 1 x Headphone and microphone combo jack
  • 1 x SmartCard Reader

Security:

  • Intel® Platform Trust Technology, Trusted Platform Module (TPM) 1.2/2.0 (Check regional availability), Chassis lock slot support
  • Support for optional Computrace and Optional Contactless SmartCard Reader/Fingerprint Reader or FIPS
  • Fingerprint reader (Check regional availability)

Dimensions and Weight:

  • Width: 14.88” / 378mm; Depth: 10.38”/ 261mm; Height (front-Rear): Front 1.09”/27.76mm – 1.3”/(33mm)
  • Starting at 2.79kg (6.16lb)

Battery:

  • 72Whr Lithium Ion polymer battery
  • 91Whr Lithium Ion polymer battery
  • 91Whr long life cycle Ion Polymer battery

Power Adaptor: 180 Watt AC adapter (7mm barrel)

Regulatory and Environmental Compliance: ENERGY STAR 6.2; EPEAT registered

TAA Configurations available: YES (Check regional availability)
