Essential Phone Repair

If you have any trouble with your Essential Phone, refer to the troubleshooting page.

The Essential phone is the first product by Essential, a company founded by Andy Rubin. The phone features a near bezel-less screen, premium components and materials, and a magnetic connector to expand the phone's functionality through Essential's line of accessories. Also notable is a complete lack of branding on the phone, as Essential wants the phone to be representative of the user, not of the Essential brand.

The Essential Phone was discontinued on December 28, 2018. Essential has yet to announce a new version of the phone.

Launch Date: August 25, 2017

Model Name: Essential PH-1

Developer: Essential Products, Inc.

Operating System: Android

Materials:

• Titanium body
• Ceramic back
• Corning Gorilla Glass 5 cover glass

Display:

• 2560 x 1312 QHD resolution
• 19:10 aspect ratio
• 5.71” LCD screen with radiused corners
• 10 finger multitouch
• 500 nits brightness (typical)
• > 1:1000 contrast ratio (typical)
• CGS / LTPS technology

Cameras:

• Rear Camera:
  • 13MP Dual RGB + Mono camera with image fusion technology
  • 13MP True Monochrome mode
  • f/1.85 lens
  • Hybrid Auto Focus combing Contrast, Phase Detect and IR Laser Assist Focus
  • Video at 4K 30fps, 1080p 60fps or 720p 120fps
• Front Camera:
  • 8MP resolution with 16:9 aspect ratio
  • f/2.20 fixed hyperfocal lens
  • Video at 4K 30fps, 1080p 60fps or 720p 120fps

System Architecture: Snapdragon 825

• CPU: Kryo 280 Octa-core (2.45GHz Quad + 1.9GHz Quad), 64 bit, 10nm processor
• GPU: Adreno 540, 710MHz, 64bit

Battery: 3040mAh

RAM: 4GB

Storage: 128GB UFS 2.1

Audio: 4 microphones with noise cancellation and beam forming

Sensors:

• Fingerprint reader: fastest available technology
• Proximity / Ambient light sensor
• Volume buttons, Power button
• Environmental pressure sensor (barometer)
• Accelerometer, Magnetometer and Gyroscope

Ports:

• USB Type-C
• 60GHz, 6 Gbps Wireless Accessory Connector
• 2x accessory power pins
• NanoSIM tray with pin eject

Connectivity:

• Bluetooth: 5.0 LE
• WiFi: 802.11a/b/g/n/ac with MIMO
• NFC: yes
• Positioning: GPS and GLONASS

Network / Bands:

• UMTS/HSPA+: 1, 2, 4, 5 6, 8
• GSM: 850, 900, 1800, 1900 MHz
• CDMA EV-DO Rev. A: 0, 1, 10
• FDD-LTE: 1, 2, 3, 4, 5, 7, 8, 11, 12, 13, 17, 20, 21, 25, 26, 28, 29, 30, 66
• TDD-LTE: 38, 39, 40, 41, 42, 43
• TD-SCDMA: 34, 39

Dimensions:

• Height: 141.5mm
• Width: 71.1mm
• Thickness: 7.8mm
• Weight: < 185 grams
