Battery
Werkzeuge
Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.
Troubleshooting
For additional help on the HP Spectre x360 13-ac023dx, refer to the device’s troubleshooting page. [[HP Spectre x360 13-ac023dx Troubleshooting|]]
Background and Identification
The HP Spectre x360 13-ac023dx is an extremely light weight laptop. At only 1.32 kilograms (or just under 3 pounds), the device can be transported easily at a compact size. The screen measures at 13.3 inches, which is on the smaller side for a laptop. It features an Intel Core 17- 7500U with Intel Burst Tool Technology. Its power supply is a 45 W AC power adapter.
The device has a full-size island-style keyboard, which uses keys in the shape of small squares with rounded corners and straight sides. It has a touch screen which measures in at 1920 x 1080 millimeters (mm). The HP Spectre x360-ac023dx’s minimum measurements are 30.7 x 21.8 x 1.39 centimeters (cm), which shows how compact the device is. The device has features such as an external port for both headphone and microphone, and an HP ImagePad which has multi- touch gesture support. This allows the touch screen to recognize the presence of more than one point of contact.
Specifications
Product number
Z4Z21UA
Product name
HP Spectre x360 - 13-ac023dx
Microprocessor
Intel® Core™ i7-7500U (2.7 GHz, up to 3.5 GHz with Intel® Turbo Boost Technology, 4 MB cache, 2 cores)
Memory, standard
16 GB LPDDR3-1866 SDRAM (onboard)
Video graphics
Intel® HD Graphics 620
Hard drive
512 GB PCIe® NVMe™ M.2 SSD
Display
13.3" diagonal FHD UWVA BrightView WLED-backlit narrow bezel multitouch-enabled edge-to-edge glass (1920 x 1080)
Keyboard
Full-size island-style backlit keyboard
Pointing device
HP Imagepad with multi-touch gesture support
Wireless connectivity
Intel® 802.11ac (2x2) Wi-Fi® and Bluetooth® 4.2 Combo (Miracast compatible)
External ports
1 headphone/microphone combo; 2 USB 3.1 Type-C™ Gen 2 (Thunderbolt, Data up to 40 GB/s, Power Delivery, DP1.2, HP Sleep and Charge); 1 USB 3.1 Gen 1 (HP Sleep and Charge)
Minimum dimensions (W x D x H)
30.7 x 21.8 x 1.39 cm
Weight
1.32 kg (2.91 lb)
Power supply type
45 W AC power adapter
Battery type
3-cell, 57.8 Wh Li-ion
Webcam
HP TrueVision FHD IR Camera with dual array digital microphone
Audio features
Bang & Olufsen; HP Audio Boost; Quad speakers
Source for specifications: ++HP Customer Support Knowledge Base++
