Background and Identification
The HTC Evo 3D is an Android based smart phone that was released on June 24th, 2011 as an exclusive Sprint device. This phone can be identified by its model number: APX515CKT. The device was announced at an HTC event during CTIA in Orlando, Florida on March 2011. The HTC Evo 3D features a 3D HD Imaging camera. The phone runs Android 2.3.4 with HTC Sense 3.0 overlay which is capable of being upgraded to Android 4.0.3 with HTC Sense 3.6 or 4.1.2 Jelly bean with CyanogenMod 10.
This phone features a 4.3 inch 3D LCD capacitive touchscreen. The back side of the phone houses the 3D camera which has two lenses used for the 3D photos. The HTC Evo 3D is a unique addition to the vast line of Android devices available. This 3D enabled devices is one of the first of its kind and made a considerable impact to the smartphone market.
Troubleshooting Page
Here is a link to the Troubleshooting Page for the HTC Evo 3D:HTC Evo 3D Troubleshooting
Device Specifications
Dimensions: 127 mm (5.0 in) H
66 mm (2.6 in) W
12 mm (0.47 in) D
Weight: 170 g (6.0 oz)
Operating system: Android 2.3.4 with HTC Sense 3.0 overlay upgradable to Android 4.0.3 with HTC Sense 3.6
CPU: Dual-Core, 1.2 GHz Qualcomm MSM8660 (Snapdragon) GPU Qualcomm Adreno 220
Memory: 1 GB RAM
Storage: 4 GB eMMC
Removable storage Micro-SDHC 8 GB (32 GB max)
Battery: 1730 mAh Lithium-ion battery
Data inputs: Multi-touch touchscreen display
3-axis accelerometer
3-axis gyroscope
Digital compass
Proximity sensor
Ambient light sensor
Display: 960×540 px, 4.3 in (10.9 cm) at 256 ppi qHD Capacitative Super-LCD (0.49 megapixels) Autostereoscopic 3D-capable
Rear camera: Backside Illumination Dual 5 megapixel autofocus with dual LED flash, rear-facing
Front camera: 1.3 megapixel, front-facing
Connectivity: Tri-band CDMA/EVDO Rev. A
(800/800ESMR[1]/1900 MHz)
2.5 to 2.7 GHz WiMAX 802.16e[2]
Wi-Fi (802.11b/g/n)[3]
Bluetooth v3.0 + HS
Micro USB
HDMI (via MHL)
Other Wi-Fi Hotspot, FM-Radio, GPS navigation
