Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.

Background and Identification

The LG Cosmos 3, also known by its model number LG-VN251S, is a slider mobile phone made by LG Electronics. The phone was only sold by Verizon Wireless in the United States. The Cosmos 3 features a four-line QWERTY keyboard on the inside portion of the phone and a numeric keypad on the front portion of the phone.

The LG Cosmos 3 features a 2.0-inch display with a resolution of 320 by 240 pixels. It includes a rear-facing 1.3-megapixel main camera. The phone was sold with either a standard battery (900 mAh) or an extended battery (1800 mAh). This model’s memory slot can support up to a 32 GB MicroSD memory card. MicroSD cards are sold separately from the phone, but a USB charging cable is sold with this model.

The LG Cosmos 3 allows users to post quick updates to Facebook. Users can also surf the Internet, text, take pictures, and send voice messages. This phone also supports Bluetooth 2.1 and S-GPS for location accuracy.

The LG Cosmos 3 includes the name “Verizon” printed in the center of the phone’s top bezel with a large check-mark next to the name. The name “LG” is printed in the center of the phone’s bottom bezel next to the LG logo, which features the letters 'LG’ stylized to look like a human face.

Technical Specifications

SUMMARY:

  • Screen Size: 2.0 inches
  • Screen Resolution: 320 x 240 pixels
  • Battery Capacity: 1,800 mAh
  • Camera Resolution: 1.3 MP
  • Storage: Expandable via microSD™ card (sold separately)
  • Carrier: Verizon
  • Other Features: Four-Line QWERTY Keyboard, Quick Updates to Facebook®, Mobile Web, Text, Picture, and Voice Messaging

TECHNICAL SPECIFICATIONS:

  • Carrier: Verizon
  • Technology: CDMA
  • Frequencies: 1.9 GHz CDMA PCS, 800 MHz CDMA (Digital Dual-Band)
  • Data Transmission: 1xRTT Voice & Data
  • Dimensions: 4.41" (H) x 2.06" (W) x 0.63" (D)
  • Weight: 4.58 oz.
  • Display: 262K Color TFT, 320 x 240 Pixels, 2.00"
  • Standard Battery: 900 mAh
  • Extended Battery: 1,800 mAh
  • Talk Time: Up to 6 Hours*
  • Standby Time: Up to 34 Days and 2 Hours
  • microSD™ Memory Slot: Supports up to a 32GB memory card**
  • UPC: 652810815260
  • *Certain features may use more power and cause actual time to vary.
  • **MicroSD cards sold separately.
  • ***USB Cable (included) and microSD card (sold separately) required.

CONNECTIVITY:

  • Mobile Web: Yes
  • Bluetooth® Version: 2.1
  • Supported Bluetooth® Profiles: Headset, hands-free, object push, advanced audio distribution (stereo), file transfer, message access, phone book access
  • BREW® Capable: Yes
  • FOTA Capable: Yes
  • GPS: S-GPS for Enhanced Location Accuracy

CAMERA/VIDEO:

  • Camera: 1.3 MP Camera
  • Camera Resolutions: 1280 x 960 (default), 640 x 480, and 320 x 240 pixels
  • Digital Zoom: Up to 2x
  • Image Editor: zoom, rotate, crop

ENTERTAINMENT:

  • Mobile Email and Instant Messaging: Yes
  • Text, Picture, and Voice Messaging: Yes
  • Music Player: Supports MP3, WMA, AAC, and AAC+ Formats
  • Music Library: Organized by artist, album, genre, or playlist
