Blade Clamping Mechanism
Werkzeuge
Es werden einige allgemeine Werkzeuge verwendet, um an diesem Gerät zu arbeiten. Du wirst nicht jedes Werkzeug für jeden Vorgang benötigen.
Troubleshooting
Please follow this link to the troubleshooting guide for the Milwaukee Hackzall 2625-20 if you are having issues.
Background and Identification
The Milwaukee Hackzall 2625-20 is a red cordless saw, also known as the Milwaukee 2625-60 M18 Reciprocating Saw. The M18 Cordless Lithium-Ion is built with a Milwaukee 4-pole motor and it has a proprietary impact mechanism that provides 1400 in-lbs of torque per minute, providing maximum productivity and runtime in its class. This tool has a variable-speed trigger that provides the user with increased control.
This decide has a one-handed design in order to increase control over the device compared to a standard reciprocating saw. The clamp itself allows for users to experience an easy and fast blade change when necessary. The device itself is lightweight so users may have an easier experience if using the device overhead. It had a one hour charing time, a keyless blade clamp, and a dual gear anti-vibration system so users can have better control.
Multiple battery packs can be used to deliver more work per charge; the REDLITHIUM Extended Capacity Battery Pack and the Compact Battery Pack are the two suggested battery packs by Milwaukee.
Specifications
Rating: 18 Volt Li-Ion
Max Torque: 1,400 in-lbs
No-load RPM: 0-2, 200
No-load BPM: 0-3, 200
Drive: 1/4” Hex
Weight: 2.6 lbs without the battery
Warranty: 5 years (limited)
Power Source: Cordless
